Product Description

1.Product Overview

TNS1CUTU is a strategic research infrastructure for scalable fault-tolerant quantum computing systems on the OSN 9800 series optical transmission platform.This product is designed to address the extreme performance challenges faced by classical control systems and data distribution networks in future large-scale quantum computers, such as those with millions of qubits.It is not a universal optical transmission device, but a cutting-edge optical interconnect research and prototype verification platform designed to meet the core requirements of quantum computing systems, such as ultra-high density control signal distribution, femtosecond level synchronization accuracy, ultra-low jitter data return, and deterministic communication topology.It is an indispensable classical network foundation for building practical fault-tolerant quantum computers.

2.Core positioning and core challenges to be addressed

Exploration of the Performance Limits of Quantum Bit Controlled Networks

Research the high fidelity and high-precision distribution capability of microwave/laser control pulses required for mainstream quantum computing routes such as superconductivity and ion traps in complex optical networks.

Explore how to achieve scaled expansion of control channels while maintaining signal integrity through advanced optical network architectures such as wavelength division multiplexing and space division multiplexing as the quantum bit scale grows exponentially.

Femtosecond level global synchronization and extremely low jitter transmission

Quantum computing operations require strict time alignment of all control signals and measurement signals (typically requiring sub nanosecond to picosecond synchronization, and future femtosecond synchronization).

This platform aims to study how to achieve femtosecond level time synchronization distribution and extremely low jitter (<10 fs RMS) signal transmission across cabinets and computing modules in a distributed optical network environment.

High speed and low-noise feedback of quantum state reading data

The analog or digital signals generated by quantum bit measurement need to be collected at high speed and low noise and transmitted back to the classical processing unit.

Platform research aims to achieve a high bandwidth and high signal-to-noise ratio measurement data optical transmission scheme in a quantum computing laboratory environment with strong electromagnetic interference.

Network topology optimization for specific quantum computing architectures

Research on deterministic, low latency, and reconfigurable optical network topology and routing algorithms that match specific architectures such as quantum error correction coding and distributed quantum computing.

3.Core architecture and key features of the system

1.Physics and System Architecture

Model: TNS1CUTU

Platform attribute: A classical control and data network research platform for scalable quantum computing

Design objective:"Extreme synchronization, ultra-low jitter, flexible topology, and full chain measurability".

2.Core subsystem

Ultra high precision time-frequency distribution subsystem:

Based on optical frequency comb or coherent optical phase transmission technology, the generation and distribution of femtosecond level stable optical frequency reference signals can be achieved.

Integrated high-precision phase detection and compensation unit, real-time correction of transmission link phase noise caused by temperature and vibration.

Low jitter control signal optical modulation and distribution subsystem:

Support the modulation of digital/analog control signals from quantum control systems onto optical carriers, and perform low-noise amplification and fan out distribution.

Key indicators: extremely low additional time jitter (<50 fs) and amplitude noise.

High bandwidth and low-noise data feedback subsystem:

Provide high-speed, high linearity, low-noise optoelectronic conversion and transmission channels for microwave reading signals or photon detector outputs of superconducting qubits.

Programmable Network Topology and Switching Subsystem:

Support the construction of various optical switching topologies such as star, ring, and grid, and can be dynamically reconstructed through software to adapt to different quantum computing architecture experimental requirements.

3.Deep open experimental and analytical interface

Physical layer performance probe: provides a picosecond level resolution measurement interface for optical signal phase, amplitude, and time-domain waveform, used to accurately characterize full link jitter and noise.

Synchronization Performance Analysis Suite: Provides a professional toolchain for measuring and evaluating the time synchronization accuracy (Allan variance, time error TIE) between remote nodes.

Control and Data Protocol Interface: Supports hardware interfaces with mainstream quantum control systems (such as Qblox, Zurich Instruments) or custom control protocols.

4.Research support system

Quantum Computing Network Collaborative Simulation Environment: Provides a joint simulation tool that combines quantum computing task scheduling and error rate models with classical network transmission delay and jitter models.

Automated benchmark testing framework: provides automated and repeatable testing and data acquisition solutions for key indicators such as control signal fidelity, synchronization accuracy, and data error rate.

Open source research module: around this platform, open source core synchronization algorithms, jitter analysis tools, and network topology configuration templates.

4.Typical frontier research directions

Research on Optical Synchronization Network Architecture for Large Scale Quantum Computing: Exploring Scalable Optical Network Architecture and Protocol for Achieving Femtosecond Level Global Synchronization among Hundreds of Distributed Quantum Computing Modules.

Research on the correlation between fidelity of control signal transmission and quantum gate error: Quantitatively study the specific effects of timing jitter and amplitude noise introduced by classical networks on the fidelity of quantum gate operation, and establish an error model.

Research on dedicated interconnect networks for quantum error correction architectures such as surface code: Design an efficient and low latency data merging and switching optical network that matches the distributed physical structure of logical qubits in surface code quantum computers.

Research on Hybrid Optical Interconnection Technology in Low Temperature and Room Temperature Regions: Exploring Optical Interconnection Solutions for Connecting Quantum Chips in Low Temperature Refrigeration Machines with Room Temperature Control Devices to Address Special Challenges such as Thermal Load and Attenuation.

Pre research on the underlying network infrastructure of quantum computing cloud platform: To study the underlying optical network technology that meets the quality of service (QoS) requirements for remote access to quantum computing resources through classical networks in the future.

5.Summary of Core Values

Cracking the key bottleneck of quantum computing scalability: providing fundamental research capabilities directly targeting the core engineering challenges that limit the scale expansion of quantum computers - classical control and interconnect networks.

Defining future quantum computing infrastructure standards: Through advanced research, it is expected to form early technical standards and patent layouts in the architecture, interfaces, performance indicators, and other aspects of quantum computing classical networks.

Accelerating the practical process of fault-tolerant quantum computing: providing an essential network layer technology verification platform for the critical transition stage from laboratory prototype to engineering scalable systems.

Cultivate leading talents in quantum systems engineering: provide an extremely complex interdisciplinary research environment covering quantum physics, precision optics, microwave engineering, high-speed communication, and systems engineering, and cultivate the next generation of strategic scientists in the field of quantum systems engineering.

6.Access and cooperation mechanism

Platform code: TNS1CUTU.

Operating mechanism: Adopting the model of"sharing core infrastructure under major strategic projects of quantum technology".The platform is uniformly planned and deployed to serve a key R&D team that has undergone rigorous review and aims to overcome the core engineering and technical challenges of scalable quantum computing systems.

User qualification: Limited to the core team responsible for major engineering and technological research and development tasks in the field of quantum computing, with clear system level research and development goals and interdisciplinary integration capabilities.

Achievement management: Research achievements focus on key engineering technological breakthroughs in scalable quantum computing systems. The core patents, technical solutions, and engineering data produced are intended to serve the overall strategic advancement in the field of quantum computing, and comply with the management and sharing standards for major technological infrastructure achievements.
