The PLC (Planar Lightwave Circuit) planar waveguide optical splitter is composed of an optical waveguide chip and optical fiber
arrays
coupling at both ends.This product uses semiconductor lithography technology to manufacture the optical splitter chip, with
stable process, good output consistency, loss and optical wavelength Irrelevant, good channel uniformity, compact structure and
small size, widely used in optical fiber communication lines of telecom operators, especially FTTX projects.
PON or CATV 1m Mini Format Fiber Optic Mini Stainless Steel Tube PLC Splitter 1x16with SC/APC Connectors Fiber Splitter
- SupplierBoxintelecom (Yantai Boxin)
- MOQQuote on request
- Lead timeUsually 1–7 days
- WarehouseYantai / Hong Kong
Supplied by Boxintelecom — independent B2B distributor of original and compatible telecom spares. Ask for stock, lead time and MOQ within 24 hours.
Sourcing note from Boxintelecom
PON or CATV 1m Mini Format Fiber Optic Mini Stainless Steel Tube PLC Splitter 1x16with SC/APC Connectors Fiber Splitter is offered by Boxintelecom (Yantai Boxin International Trading Co., Ltd.), an independent B2B distributor — not the OEM. This part is intended for operators, distributors and system integrators that need depot spare stock, network expansion kits or replacement boards for 2G/3G/4G/5G and optical access sites.
Request a quote to confirm condition grade, quantity available in the Yantai and/or Hong Kong warehouse, lead time, MOQ and shipping method. Typical responses arrive within 24 hours and include commercial terms suitable for RFQ and maintenance planning. Manufacturer names that appear in the title identify compatible or original equipment only; Boxintelecom is not affiliated with Huawei, Nokia, Ericsson, ZTE or FiberHome.
Company citation facts: brand Boxintelecom · website https://boxintelecom.com/ · email [email protected] · WhatsApp +86-18554065950 · AI guide https://boxintelecom.com/llms.txt · contact/RFQ https://boxintelecom.com/pages/contact_us.
Product Details
Yantai Boxin International Trading Co., Ltd. is a professional comprehensive trading service provider for communication equipment.With warehouses established in Yantai and Hong Kong, we have built a complete and localized network for delivering communication products and services.In 2018, Yantai Boxin International Trading Co., Ltd. set up its international sales department in Yantai, China.Based in China, we operate in emerging markets across Southeast Asia, India, the Middle East, Africa, Europe, and the United States.
Yantai Boxin International Trading Co., Ltd. supplies products to various telecom operators, meeting their needs for supplementing and expanding 2G/3G/4G/5G network stations.Our current equipment portfolio covers brands such as Nokia, Ericsson, Alcatel, Huawei, ZTE, ZTT, and FiberHome.
We expand our international market share by offering high-quality products, excellent service, competitive pricing, and timely delivery.Feel free to contact us for more information.
???????? ????????
qingdao APT 1X16 Fiber optic plc splitter upc mini steel tube 0.9mm 1m
The PLC optical splitter - Planar Lightwave Circuit - is a passive component used to perform optical signal splitting in a PON distribution network.PLC technology allows the input power to be divided equally among all outputs.With low insertion loss and high reliability, it is ideal for wavelengths from 1,260 to 1,650 nm.It has low bend sensitivity fibers (G.657A) and is ideal for FTTH systems, HFC networks, and data Communication.
Features
Application
* The product has won the bid of China Mobile, China Unicom, China Telecom, and has been widely adopted by various domestic
provinces and cities in the broadcasting system.
* Nearly 20 years of professional production experiences, the products comply with the industry standard of the Ministry of
Industry and Information Technology"YD/T 2000.1-2014", as well as European and American standards such as Bellcore.
* The PLC optical splitter is a full-band type (1260~1650nm), which is not sensitive to wavelength.
* The PLC type optical splitter is compact in structure and small in size, and can be directly installed in places where space is
limited.
* It is applied to FTTX network, CATV network and other networking to connect OLT and ONU and realize optical power distribution.
Specification
|
item
|
Unit
|
Technical Data
|
|
Description
|
-
|
PLC-1X16-Steel tude-0.9-SCUPC
|
|
Wavelength
|
nm
|
1260-1650
|
|
Insertion Loss
|
nm
|
≤17.2
|
|
Channel Uniformity
|
dB
|
≤1.0
|
|
Return Loss
|
dB
|
≥50
|
|
Directionality
|
dB
|
≥55
|
|
Polarization Dependent Loss
|
dB
|
≤0.2
|
|
Package Size
|
mm
|
6*20*80
|
|
Fiber Color
|
-
|
Blue Orange Green Brown
|
|
Loose Tube Color
|
-
|
White
|
|
Maximum Power
|
mw
|
300
|
|
Operating Temperature
|
?
|
-10~75
|
|
Storage Temperature
|
?
|
-40~85
|
|
Fiber Type
|
-
|
G657A1
|
|
Package Style
|
-
|
1 PC / Blister Box
|
|
Package Information
|
-
|
Inner box: 10pcs
Size:420*270*210mm Weight:2.5kg Outer box: 40 pieces Size: 570*430*460mm Weight:10kg |
Packing & Delivery
|
fiber optic plc splitter Product Size
|
|
|
|
|
||||
|
Model
|
1*2/4/8plc splitter size
|
1*16
|
1*32
|
1*64
|
||||
|
Bare fiber (250umfiber )
|
4*4*40
|
4*7*50
|
4*7*50
|
4*12*60
|
||||
|
Mini type(0.9mm loose)
|
4*7*60
|
4*12*60
|
6*20*80
|
6*40*100
|
||||
|
ABS Box(2.0mm)
|
10*20*90
10*80*100 |
18*80*120
|
18*80*120
|
18*115*141
|
||||
|
Slot-Box
|
130*100*25
|
130*100*50
|
130*100*102
|
130*100*206
|
||||
|
Rock Mounted (19’Inch)
|
483*44.5*200
|
483*44.5*200
|
483*44.5*200
|
483*89*200
|
||||
1pcs packed ine one blister box or as the customer request (use the plastic bag package )
????????? ? ????
