ETP48100 B1 50A 100A HW olt power supply Support all DC OLT Power converter 1U power supply AC DC OLT rectifier
$250.00 USD
Izračun stroškov prevoza na blagajni
Količina
Product Description
Product Description
ETP48100 is an AC-DC embedded power system with excellent performance such as high power efficiency,
intelligent battery management, remote management, wide range of AC input voltage, etc.The system can configure 2 pieces of 1U
50A high rectifier modules, and provides 30A rated current output.ETP48100-B1 can be embedded in 19-inch rack or cabinet.This
series of embedded power products includes 5 types of products: ETP4830, ETP4890, ETP48150, ETP48200 and ETP48400.They can
provide wide range of DC output from 30A to 400A, and are very broad application in DC power system scenarios.The functional unit
using a standardized installation structure design, power height ranging from 1U to 11U, compact design, support 19-inch rack or
cabinet installation.The system can be adapted to a wide range of AC input voltage, with intelligent battery management, remote
monitoring, etc.
intelligent battery management, remote management, wide range of AC input voltage, etc.The system can configure 2 pieces of 1U
50A high rectifier modules, and provides 30A rated current output.ETP48100-B1 can be embedded in 19-inch rack or cabinet.This
series of embedded power products includes 5 types of products: ETP4830, ETP4890, ETP48150, ETP48200 and ETP48400.They can
provide wide range of DC output from 30A to 400A, and are very broad application in DC power system scenarios.The functional unit
using a standardized installation structure design, power height ranging from 1U to 11U, compact design, support 19-inch rack or
cabinet installation.The system can be adapted to a wide range of AC input voltage, with intelligent battery management, remote
monitoring, etc.
Default configuration
Input:100-120V / 200-240V
Output:48V;50A
Rectifier module: R4850G*1
Apply to:Huawei/Fiberhome/ZTE OLT
Special required configuration:
Input:100-120V / 200-240V
Output:48V;100A
Rectifier module: R4850G*2
Apply to:Huawei/Fiberhome/ZTE OLT
Product Features
• Support wide range of DC output from 30A to 400A;
• High rectifier efficiency over 96% helps to save energy, derated output above 55℃;
• Rectifier with MTBF>500,000h helps to save OPEX;
• E-label function, can achieve assets management of the whole site,
easy for assets management and location of problem quality;
easy for assets management and location of problem quality;
• Battery anti-reversed connection function, avoid the possible of equipment loss and personal safety accident
• Complete system management function, LCD visualization monitoring;
• Support multiple interfaces, convenient remote centralized management.
Specification
|
item
|
value
|
|
Model Number
|
ETP48100
|
|
Type
|
Telecom Power
|
|
Place of Origin
|
China
|
|
Brand Name
|
Original
|
|
Product name
|
ETP48100
|
|
Warranty
|
1 Year
|
|
Certificate
|
CE
|
|
Package
|
Standard
|
|
Color
|
Silver
|
|
Condition
|
Brand-new
|
|
Feature
|
safety
|
