HG8540M GPON ONU 1GE 3FE Ports BOT Outlet Fiber Optic Modem XPON FTTH
HG8540M GPON ONT series equipments are manufactured and developed, which is a leader in FTTH/ FTTO broadband access network field.They are properly manageable added with features such as high-bandwidth, high reliability, low power consumption and satisfy the users requirement to access broadband, voice, data and video etc.
HG8540M with 4*FE/1GE+3*FE ports.
The HG8540M, an optical network terminal (ONT), is a high-end home gateway in FTTH solution.By using the GPON technology, ultra-broadband access is provided for home and SOHO users.
The HG8540M features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services.Therefore, the HG8540M provides a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment.
|
Technical items |
Descriptions |
|
Fiber port |
1 GPON interface, 1GE+3FE+1POT+USB+WIFI,SC single-mode, or 1 GPON interface, 4FE+1POT+USB+WIFI,SC single-mode, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps |
|
Wavelength |
Tx 1310nm, Rx 1490nm |
|
Fiber interface |
SC/UPC |
|
RX sensitivity |
<-27dBm (1490nm) |
|
Wi-Fi |
IEEE802.11b/g/n, 2*2 MIMO, 2*External antenna,WPS,WiFi Multi Media |
|
LAN |
1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface |
|
Throughput |
Downstream 950Mbps,Upstream 930Mbps |
|
ONT Detection and Isolation of Active/Passive Hooligans |
YES |
|
Button |
Reset, power |
|
Power |
≤8W |
|
Dimension |
180*140*30mm(length*width*height) |
|
Net weight |
≤0.8Kg |
