deye Hybrid Inverter 12kw MPPT 8kw 10kw 12kw Solar Inverter Price Poland Power Inverter

Yantai Boxin International Trading Co., Ltd. is a professional comprehensive trading service provider for communication equipment.With warehouses established in Yantai and Hong Kong, we have built a complete and localized network for delivering communication products and services.In 2018, Yantai Boxin International Trading Co., Ltd. set up its international sales department in Yantai, China.Based in China, we operate in emerging markets across Southeast Asia, India, the Middle East, Africa, Europe, and the United States.

Yantai Boxin International Trading Co., Ltd. supplies products to various telecom operators, meeting their needs for supplementing and expanding 2G/3G/4G/5G network stations.Our current equipment portfolio covers brands such as Nokia, Ericsson, Alcatel, Huawei, ZTE, ZTT, and FiberHome.

We expand our international market share by offering high-quality products, excellent service, competitive pricing, and timely delivery.Feel free to contact us for more information.

Products Description

Model	SUN-8K-SG01LP3	SUN-10K-SG01LP3	SUN-12K-SG01LP3
DC input
Max.input power	10.4KW	13KW	15.6KW
Max.PV voltage	800V
MPPT range	140-700V
Max. input current	12.5A+12.5A	25A+12.5A	25A+25A
MPPT tracker/arrays	2/1	2/1	2/1
AC output
Max.output power	8.8KVA	11KVA	13.2KVA
Max.output current	12.8A	18A	19.1A
Max.input power	17.6KVA	22KVA	26.4KVA
Max.input current	25.4A	31.8A	38.1A
Nominal voltage/range	50/60Hz; 230/400Vac (Three phase)
Frequency	50 /60Hz
PF	1(0.8lagging-0.8leading)
THDI	<3%
Current Harmonic Distortion	THD<3% (Linear load<1.5%)
Battery
Battery voltage range	40-60V
Charge/discharge current	190A	210A	240A
Charging Curve	3 Stages / Equalization
External Temperature Sensor	Optional
Charging Strategy for Li-Ion Battery	Self-adaption to BMS
Protection
PV Input Lightning Protection	Integrated
Anti-islanding Protection	Integrated
PV String Input Reverse	Integrated
Polarity Protection	Integrated
Insulation Resistor Detection	Integrated
Residual Current Monitoring Unit	Integrated
Output Over Current Protection	Integrated
Output Shorted Protection	Integrated
Output Over Voltage Protection	Integrated
Surge protection	DC Type II / AC Type II
General data
DC max.efficiency	97.6%
Euro efficiency	97%
MPPT efficiency	99%
Protection class	IP65
Noise emission (typical)	< 30dB
Operation temperature	-25~60℃,>45℃ Derating
Cooling	Smart cooling
Communication with BMS	RS485; CAN
Altitude	2000m
Dimensions (WXDXH)	420W×656H×281D
Weight	45kg
Installation Style	Wall-mounted
Warranty	5years
Features
Grid Regulation	UL1741, IEEE1547, RULE21, VDE 0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116, IEC61727
Safety Regulation	IEC62109-1, IEC62109-2
EMC	EN61000-6-1, EN61000-6-3, FCC 15 class B

Packing & Delivery

Model	SUN-5K/8K-SG01LP1-EU
Pallet	8pcs/pallet
20GP	100pcs/20GP
