CloudEngine S16700 Series Switches 03050JNP LSH7SFUHX100 S16700-8 Switch Fabric Unit H (X1)

Name: CloudEngine S16700 Series Switches 03050JNP LSH7SFUHX100 S16700-8 Switch Fabric Unit H (X1)
Price: 850 USD
Availability: InStock

$850.00 USD

Tính phí vận chuyển khi thanh toán

Số lượng

Yantai Boxin International Trading Co., Ltd. is a professional comprehensive trading service provider for communication equipment.With warehouses established in Yantai and Hong Kong, we have built a complete and localized network for delivering communication products and services.In 2018, Yantai Boxin International Trading Co., Ltd. set up its international sales department in Yantai, China.Based in China, we operate in emerging markets across Southeast Asia, India, the Middle East, Africa, Europe, and the United States.

Yantai Boxin International Trading Co., Ltd. supplies products to various telecom operators, meeting their needs for supplementing and expanding 2G/3G/4G/5G network stations.Our current equipment portfolio covers brands such as Nokia, Ericsson, Alcatel, Huawei, ZTE, ZTT, and FiberHome.

We expand our international market share by offering high-quality products, excellent service, competitive pricing, and timely delivery.Feel free to contact us for more information.

Product Description

CloudEngineS16700 Introduction

CloudEngine S16700 series switches (S16700 for short) are next-generation modular core switches designed for high-end campus networks in the all-wireless era.S16700 series switches consist of two models with four Line Processing Unit (LPU) slots and eight LPU slots respectively.They provide ultra-high-density full-rate access ports, meeting customers' requirements for quickly building campus networks with simplified architecture.S16700 series switches use Hua wei's next-generation converged software platform to provide customers with a trusted platform system and secure data access.Key components, such as main control boards, power modules, and fan modules, adopt redundancy design to provide carrier-class reliability.The switches are ideal aggregation and access nodes for building cloud campus networks, helping global customers achieve their digital transformation goals.

Technical Specifications	S16700-4	S16700-8
Height [mm]	438 mm	703 mm
Depth [mm]	874 mm	874 mm
Width [mm]	442 mm	442 mm
Chassis height [U]	9.8	15.8
Weight without packaging	94.1 (207.45)	129.8 (286.16)
Weight with packaging	138 (304.23)	177 (390.21)
Maximum power consumption [W]	4664	8260
Heat dissipation mode	Drawing air for heat dissipation	Drawing air for heat dissipation
Maximum heat dissipation [BTU/h]	15914	28183
Input voltage range [V]	AC: 220 V; 50 Hz/60 Hz High-voltage DC (HVDC): 240 V/380 V	AC: 176 V to 290 V; 45 Hz to 65 Hz High-voltage DC (HVDC): 188 V to 288 V or 260 V to 400 V
Rated input voltage [V]	AC: 176 V to 290 V; 45 Hz to 65 Hz High-voltage DC (HVDC): 188 V to 288 V or 260 V to 400 V	AC: 220 V; 50 Hz/60 Hz High-voltage DC (HVDC): 240 V/380 V
Number of MPU slots	2	2
Number of power slots	6	10
Number of service board slots	4	8
Number of SFU slots	9	9
Redundant Switch fabrics	N+M	N+M
Redundant power supply	Dual-input power supply system: N+1 backup is recommended. Single-input power supply system: N+1 backup Dual-input power supply is recommended to ensure reliability.	Dual-input power supply system: N+1 backup is recommended. Single-input power supply system: N+1 backup Dual-input power supply is recommended to ensure reliability.
Redundant MPUs	1:01	1:01
Redundant fans	Fan modules work in hot standby mode.At the normal temperature range, the system can operate properly for a short time after a single fan module fails.You are advised to replace the faulty fan module immediately.	Fan modules work in hot standby mode.At the normal temperature range, the system can operate properly for a short time after a single fan module fails.You are advised to replace the faulty fan module immediately.
Automatic fan speed adjustment	Supported	Supported
Airflow direction	Front-to-rear airflow	Front-to-rear airflow
Long-term operating temperature	0°C to 40°C (32°F to 140°F)	0°C to 40°C (32°F to 140°F)
Storage temperature	–40°C to +70°C (–40°F to +158°F)	–40°C to +70°C (–40°F to +158°F)
Restriction on the operating temperature variation rate	When the altitude is 1800 m to 5000 m (5905.44 ft. to 16404.00 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).	When the altitude is 1800 m to 5000 m (5905.44 ft. to 16404.00 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
Long-term operating relative humidity [RH]	5% RH to 85% RH (non-condensing)	5% RH to 85% RH (non-condensing)
Long-term operating altitude	≤ 5000 m (16404 ft.)	≤ 5000 m (16404 ft.)
Storage altitude	≤ 5000 m (16404 ft.)	≤ 5000 m (16404 ft.)
MTBF [year]	34.93	34.55
MTTR [h]	1	1
Availability	0.99999717	0.999997158
Maximum number of 100GE ports	144	288
Maximum number of 40GE ports	144	288
Maximum number of 10GE ports	192	384
Maximum number of GE ports	192	384
PoE	Not supported	Not supported
Maximum power output capability (including the system power output and PoE power output) [W]	5+1 backup: 3000 W x 5 = 15000 W 6+0 backup: 3000 W x 6 = 18000 W	9+1 backup: 3000 W x 9 = 27000 W 10+0 backup: 3000 W x 10 = 30000 W

Ordering information

The following table lists ordering information for theCloudEngine S16700series switches.

Part Number	Model	Description
02355HUL	EX1BS16704SA0	S16700-4 AC/HVDC assembly chassis
02355HUM	EX1BS16704SD0	S16700-4 DC assembly chassis
2122487	FAN-240SA-B	Fan Tray Assembly
03050KLA	LSH7MPUAX1T0	S16700 Main Processing Unit A (HTM)
03050JNL	LSH7SFUAX100	S16700-4 Switch Fabric Unit A (X1)
03050JNM	LSH7SFUBX100	S16700-4 Switch Fabric Unit B (X1)
2116250	GXRACK-A610A	2.2m Galaxy Assembly Cabinet-A610-22
2116249	GXRACK-A612A	2.2m Galaxy Assembly Cabinet-A612-22
02355HUN	EX1BS16708SA0	S16700-8 AC/HVDC assembly chassis
02355HUP	EX1BS16708SD0	S16700-8 DC assembly chassis
2122486	FAN-480SA-B	Fan Tray Assembly
03050JNN	LSH7SFUGX100	S16700-8 Switch Fabric Unit G (X1)
03050JNP	LSH7SFUHX100	S16700-8 Switch Fabric Unit H (X1)
Interface Card
03050JNK	LSH7X48SX1E0	48-Port 10G Optical Interface Card (X1E, SFP+)
03050JNJ	LSH7L24QX1E0	24-Port 40G Optical Interface Card (X1E, QSFP+)
03050JNH	LSH7L36QX1E0	36-Port 40G Optical Interface Card (X1E, QSFP+)
03050JNG	LSH7C18HX1E0	18-Port 100G Optical Interface Card (X1E, QSFP28)
03050JNF	LSH7C36HX1E0	36-Port 100G Optical Interface Card (X1E, QSFP28)
2122538	CR8MP2KHDCC0	380VDC HVDC Power Distribution Unit
02312JEA	PAH-3000WA	3000W Dual Inputs AC&HVDC Power Module
02312GDC	PDC-2200WC	PSU-PDC-2200WC-PM2200W DC Power Supply
2122145	CR5MDPD12500	DPD125-12-24 DC Power Distribution Box
2122537	CR8MP2K3PHC0	AC Power Distribution Unit
02354GYS	APD32-4-24	APD32-4-24 AC Power Distribution Unit
02354GYQ	APD32-12-24	APD32-12-24 AC Power Distribution Unit
02354GYV	APD63-2-24	APD63-2-24 AC Power Distribution Unit
02354GYT	APD63-6-24	APD63-6-24 AC Power Distribution Unit
Optical Transceiver
2314171	SFP-1000BaseT	Electrical Transceiver,SFP,GE,Electrical Interface Module(100m,RJ45)
02313URG	SFP-1000BaseT	Electrical Transceiver,SFP,GE,Electrical Interface Module(100m,RJ45)
2315204	eSFP-GE-SX-MM850	Optical Transceiver,eSFP,GE,Multi-mode Module(850nm,0.55km,LC)
02313URD	eSFP-GE-SX-MM850	Optical Transceiver,eSFP,GE,Multi-mode Module(850nm,0.55km,LC)
2315200	SFP-GE-LX-SM1310	Optical Transceiver,eSFP,GE,Single-mode Module(1310nm,10km,LC)
02313URF	SFP-GE-LX-SM1310	Optical Transceiver,eSFP,GE,Single-mode Module(1310nm,10km,LC)
2317346	S-SFP-GE-LH40-SM1310	Optical Transceiver,eSFP,GE,Single-mode Module(1310nm,40km,LC)
2317347	S-SFP-GE-LH40-SM1550	Optical Transceiver,eSFP,GE,Single-mode Module(1550nm,40km,LC)
2317348	S-SFP-GE-LH80-SM1550	Optical Transceiver,eSFP,GE,Single-mode Module(1550nm,80km,LC)
02314BDD	SFP-1000BaseT-G2	Electrical Transceiver,SFP,GE,Electrical Interface Module(100m,RJ45)
02310MNW	SFP-10G-USR	10GBase-USR Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.1km,LC)
02313URN	SFP-10G-USR	10GBase-USR Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.1km,LC)
2318169	OMXD30000	Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.3km,LC)
02313URC	OMXD30000	Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.3km,LC)
2318170	OSX010000	Optical Transceiver,SFP+,10G,Single-mode Module(1310nm,10km,LC)
02313URK	OSX010000	Optical Transceiver,SFP+,10G,Single-mode Module(1310nm,10km,LC)
02310CNF	OSX040N01	Optical Transceiver,SFP+,10G,Single-mode Module(1550nm,40km,LC)
02314KKG	OSX040N01	Optical Transceiver,SFP+,10G,Single-mode Module(1550nm,40km,LC)
02310SNN	SFP-10G-ZR	10GBase-ZR Optical Transceiver,SFP+,10G,Single-mode Module(1550nm,80km,LC)
02310QDJ	SFP-10G-LR	Optical Transceiver,SFP+,10G,Single-mode Module(1310nm,10km,LC)
02313URL	SFP-10G-LR	Optical Transceiver,SFP+,10G,Single-mode Module(1310nm,10km,LC)
02312UUF	SFP-10G-iLR-C	Optical Transceiver,SFP+,9.8G,Single-mode Module(1310nm,1.4km,LC)
02310MHR	QSFP-40G-iSR4	40GBase-iSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.15km,MPO)(connecting to one QSFP+ or four SFP+)
02313URW	QSFP-40G-iSR4	40GBase-iSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.15km,MPO)(connecting to one QSFP+ or four SFP+)
02310RMB	QSFP-40G-eSR4	40GBase-eSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.3km,MPO)(connecting to one QSFP+ or four SFP+)
02313URU	QSFP-40G-eSR4	40GBase-eSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.3km,MPO)(connecting to one QSFP+ or four SFP+)
02313NUG	QSFP-40G-LX4-MM	40GBase-LX4-MM Optical Transceiver,QSFP+,40GE,Multi-mode(1310nm,0.15km,LC)
02310MHS	QSFP-40G-LR4	40GBASE-LR4 optical transceiver, QSFP+, 40G, single-mode module (1310nm, 10km, LC)
02313URY	QSFP-40G-LR4	40GBASE-LR4 optical transceiver, QSFP+, 40G, single-mode module (1310nm, 10km, LC)
02311YVB	QSFP-40G-LR4-Lite	40GBase-LR4 Lite Optical Transceiver,QSFP+,40G,Single-mode Module(1310nm,2km,LC)
02313URS	QSFP-40G-LR4-Lite	40GBase-LR4 Lite Optical Transceiver,QSFP+,40G,Single-mode Module(1310nm,2km,LC)
02311MNN	QSFP-100G-CWDM4	100GBase-CWDM4 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,2km,LC)
02312VSP	QSFP28-100G-DR	100GBase,DR,Optical Transceiver,QSFP28,100G,Single-mode module (1311nm,0.5km,LC)
02311KNU	QSFP28-100G-LR4	100GBase-LR4 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,10km,LC)
02313URT	QSFP28-100G-LR4	100GBase-LR4 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,10km,LC)
02311GBW	QSFP28-100G-SR4	100GBase-SR4 Optical Transceiver, QSFP28, 100G, Multi-mode (850nm, 0.1km, MPO)
02313URQ	QSFP28-100G-SR4	100GBase-SR4 Optical Transceiver, QSFP28, 100G, Multi-mode (850nm, 0.1km, MPO)
02311MNM	QSFP28-100G-PSM4	100GBase-PSM4 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,0.5km,MPO)
02311QUK	QSFP-100G-SWDM4	100GBase-SWDM4 Optical Transceiver,QSFP28,100GE,Multi-mode Module(850nm,0.075km-OM3,0.1km-OM4,LC)
02313HLU	QSFP-100G-ER4	100GBase-ER4 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,40km,LC)
02314HES	QSFP-100G-ER4	100GBase-ER4 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,40km,LC)
02314BDE	QSFP-100G-FR1	100GBase-FR1 Transceiver,QSFP28,100G,Single-mode Module(1310nm,2km,LC)
02314DBX	QSFP-100G-LX4-MM	High Speed Transceiver,QSFP28,1310nm,4*25.78G,-3dBm,4.5dBm,-10dBm,LC,MMF,0.1km
02312QTL	QSFP-100G-4WDM-40	100GBase-4WDM-40 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,40km,LC)
02312UJN	QSFP-100G-CWDM4-Lite	100GBase-CWDM4-Lite Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,0.5km,LC)
2315286	SFP-GE-LX-SM1490-BIDI	Optical Transceiver,eSFP,GE,BIDI Single-mode Module(TX1490/RX1310,10km,LC)
02314KKH	SFP-GE-LX-SM1490-BIDI	Optical Transceiver,eSFP,GE,BIDI Single-mode Module(TX1490/RX1310,10km,LC)
2315285	SFP-GE-LX-SM1310-BIDI	Optical Transceiver,eSFP,GE,BIDI Single-mode Module(TX1310/RX1490,10km,LC)
02314KKJ	SFP-GE-LX-SM1310-BIDI	Optical Transceiver,eSFP,GE,BIDI Single-mode Module(TX1310/RX1490,10km,LC)
02310KVU	LE2MGSC40ED0	Optical Transceiver,eSFP,GE,BIDI Single-mode Module(TX1490/RX1310,40km,LC)
02310KVV	LE2MGSC40DE0	Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1310/RX1490, 40km, LC)
02310QBJ	SFP-10G-BXU1	10GBase,BIDI Optical Transceiver,SFP+,10G,Single-mode Module(TX1270nm/RX1330nm,10km,LC)
02310QDT	SFP-10G-BXD1	10GBase,BIDI Optical Transceiver,SFP+,10G,Single-mode Module(TX1330nm/RX1270nm,10km,LC)
02311BJB	SFP-10G-ER-SM1330-BIDI	Optical Transceiver,SFP+,10G,BIDI Single-mode Module(TX 1330nm/RX 1270nm,40km,LC)
02311BJC	SFP-10G-ER-SM1270-BIDI	Optical Transceiver,SFP+,10G,BIDI Single-mode Module(TX 1270nm/RX 1330nm,40km,LC)
Software
88038HBE	L-MLIC-S167	S167 Series Basic SW,Per Device
88038GGY	N1-S167-M-Lic	S167 Series Basic SW,Per Device
88062YEV	N1-S167-M-SnS-3Y	S167 Series Basic SW,SnS,Per Device,3 Year
88038GGV	N1-S167-F-Lic	N1-CloudCampus,Foundation,S167 Series,Per Device
88062YFA	N1-S167-F-SnS-3Y	N1-CloudCampus,Foundation,S167 Series,SnS,Per Device,3 Year( Annual fee validity period:3 years from" 90 days after PO signed" )
88038GVY	N1-S167-A-Lic	N1-CloudCampus,Advanced,S167 Series,Per Device
88062YFE	N1-S167-A-SnS-3Y	N1-CloudCampus,Advanced,S167 Series,SnS,Per Device,3 Year
88038HAK	N1-S167-MToF-Lic	N1-Upgrade-Basic Software to Foundation,S167 Series,Per Device
88062YFU	N1-S167-MToF-SnS-3Y	N1-Upgrade-Basic Software to Foundation,S167 Series,SnS,Per Device,3 Year
88038GWA	N1-S167-FToA-Lic	N1-Upgrade-Foundation to Advanced,S167 Series,Per Device
88062YFJ	N1-S167-FToA-SnS-3Y	N1-Upgrade-Foundation to Advanced,S167 Series,SnS,Per Device,3 Year
88036KSK	N1-AM-30-Lic	N1-CloudCampus, Add-On Package, Access Management, Per 30 Endpoints
88062GMD	N1-AM-30-SnS-3Y	N1-CloudCampus, Add-On Package, Access Management, Software Subscription and Support, Per 30 Endpoints,3 Years
88036KSL	N1-EPNP-30-Lic	N1-CloudCampus, Add-On Package, Endpoints Plug and Play, Per 30 Endpoints
88062GMH	N1-EPNP-30-SnS-3Y	N1-CloudCampus, Add-On Package, Endpoints Plug and Play, Software Subscription and Support, Per 30 Endpoints,3 Years
88036KSM	N1-APP-X7MSwitch	N1-CloudCampus, Add-On Package, Intelligent Application Analysis, X7 Series Modular Switch, Per Device
88062GMT	N1-APP-X7MSwitch-SnS-3Y	N1-CloudCampus, Add-On Package, Intelligent Application Analysis, X7 Series Modular Switch, Software Subscription and Support, Per Device,3 Year
88038HAP	N1-S167-SRv6-Lic	N1-CloudCampus,Add-On Package,SRv6,S167 Series,Per Device
88062YGL	N1-S167-SRv6-SnS-3Y	N1-CloudCampus,Add-On Package,SRv6,S167 Series,SnS,Per Device,3 Year
