Handheld Drone Detection Early Warning Defence System UAV FPV RF Detector Device for FTTH
|
Electrical specifications
|
|
|
|
||
|
Frequency Range(MHz)
|
698-4000
|
|
|
||
|
Gain at mid Tilt(dBi)
|
9.5±1; 10.5±1; 11±1
|
|
|
||
|
VSWR..
|
≤1.8
|
|
|
||
|
Polarization
|
±45°
|
|
|
||
|
Retum Loss
|
<14
|
|
|
||
|
PIM, 3rd Order, 2 x 20W (dBc)
|
-153
|
|
|
||
|
Maximum input power (W)
|
50
|
|
|
||
|
Lightning protection
|
DC Ground
|
|
|
||
|
Impedance (Ω)
|
50
|
|
|
||
|
Mechanical Specification
|
|
|
|
||
|
Connector Type
|
N-female
|
|
|
||
|
Connector position
|
Bottom
|
|
|
||
|
Size (mm)
|
440×210×65
|
|
|
||
|
Antenna Weight (kg)
|
0.65
|
|
|
||
|
Rated wind velocity (m/s)
|
36.9
|
|
|
||
|
Operational Temperature
|
-40~55 C°
|
|
|
||
|
Radome material
|
ABS, White, RAL9003
|
|
|
||
|
Mounting hardware (mm)
|
φ35~φ50
|
|
|
||
|
item
|
value
|
|
Type
|
Communication Antennas
|
|
Model Number
|
K7-LPDA-740-10/11NF
|
|
Place of Origin
|
China
|
|
|
Guangdong
|
|
Brand Name
|
