Deye Micro Inverter 1kw SUN1000G3-EU-230 on Grid Grid-tied Solar Power Inverter
1601268980885_On-Grid Solar System_1000W
Yantai Boxin International Trading Co., Ltd. is a professional comprehensive trading service provider for communication equipment.With warehouses established in Yantai and Hong Kong, we have built a complete and localized network for delivering communication products and services.In 2018, Yantai Boxin International Trading Co., Ltd. set up its international sales department in Yantai, China.Based in China, we operate in emerging markets across Southeast Asia, India, the Middle East, Africa, Europe, and the United States.
Yantai Boxin International Trading Co., Ltd. supplies products to various telecom operators, meeting their needs for supplementing and expanding 2G/3G/4G/5G network stations.Our current equipment portfolio covers brands such as Nokia, Ericsson, Alcatel, Huawei, ZTE, ZTT, and FiberHome.
We expand our international market share by offering high-quality products, excellent service, competitive pricing, and timely delivery.Feel free to contact us for more information.
|
Model
|
SUN2000G3-EU-230
|
|
|
Input Data(DC)
|
|
|
|
Recommended input power(STC)
|
210-600W (4 Pieces)
|
|
|
Maximum input DC voltage
|
60V
|
|
|
MPPT voltage range
|
25-55V
|
|
|
Full load DC voltage range(V)
|
40-55V
|
|
|
Max.DC short circuit current
|
4x19.5A
|
|
|
Max.input current
|
4x13A
|
|
|
No.of MPPT trackers
|
4
|
|
|
No.of Strings per MPP tracker
|
1
|
|
|
Output Data(AC)
|
|
|
|
Rated output power
|
2000W
|
|
|
Rated output current
|
8.7A
|
|
|
Nominal voltage/range(this may vary with grid standards)
|
230V/0.85Un-1.1Un
|
|
|
Nominal Frequency/Range
|
50/60Hz
|
|
|
Extended Frequency/Range
|
45-55Hz/55-65Hz
|
|
|
Power Factor
|
﹥0.99
|
|
|
Maximum units per branch
|
3
|
|
|
Efficiency
|
|
|
|
CEC Weighted Efficiency
|
95%
|
|
|
Peak Inverter Efficiency
|
96.50%
|
|
|
Static MPPT Efficiency
|
99.00%
|
|
|
Night Time Power Consumption
|
50mW
|
|
|
Mechanical Data
|
|
|
|
Ambient Temperature Range
|
-40~65℃
|
|
|
Size(mm)
|
267Wx300Hx42D(without mounting brack and cable)
|
|
|
Weight(kg)
|
5.2
|
|
|
Cooling
|
Natural cooling
|
|
|
Enclosure Environmental Rating
|
IP67
|
|
|
Features
|
|
|
|
Compatibility
|
Compatible with 60-72 cell PV modules
|
|
|
Communication
|
Power line/WIFI/Zigbee
|
|
|
Grid Connection Standard
|
EN50549-1, VDE0126-1-1, VDE 4105, ABNT NBR 16149, ABNT NBR 16150, ABNT NBR 62116, RD1699, UNE 206006 IN, UNE 206007-1 IN, IEEE1547
|
|
|
Safety EMC/Standard
|
UL 1741, IEC62109-1/-2, IEC61000-6-3, IEC61000-3-2, IEC61000-3-3
|
|
|
Warranty
|
10 years
|
|
Contact Us
Yantai Boxin International Trade Co., Ltd.
Click the number to chat on WhatsApp or send an email. WeChat ID is the same as the phone number.
Yantai Boxin International Trading Co., Ltd. is a professional comprehensive trading service provider for communication equipment.With warehouses established in Yantai and Hong Kong, we have built a complete and localized network for delivering communication products and services.In 2018, Yantai Boxin International Trading Co., Ltd. set up its international sales department in Yantai, China.Based in China, we operate in emerging markets across Southeast Asia, India, the Middle East, Africa, Europe, and the United States.
Yantai Boxin International Trading Co., Ltd. supplies products to various telecom operators, meeting their needs for supplementing and expanding 2G/3G/4G/5G network stations.Our current equipment portfolio covers brands such as Nokia, Ericsson, Alcatel, Huawei, ZTE, ZTT, and FiberHome.
We expand our international market share by offering high-quality products, excellent service, competitive pricing, and timely delivery.Feel free to contact us for more information.
|
Model
|
SUN2000G3-EU-230
|
|
|
Input Data(DC)
|
|
|
|
Recommended input power(STC)
|
210-600W (4 Pieces)
|
|
|
Maximum input DC voltage
|
60V
|
|
|
MPPT voltage range
|
25-55V
|
|
|
Full load DC voltage range(V)
|
40-55V
|
|
|
Max.DC short circuit current
|
4x19.5A
|
|
|
Max.input current
|
4x13A
|
|
|
No.of MPPT trackers
|
4
|
|
|
No.of Strings per MPP tracker
|
1
|
|
|
Output Data(AC)
|
|
|
|
Rated output power
|
2000W
|
|
|
Rated output current
|
8.7A
|
|
|
Nominal voltage/range(this may vary with grid standards)
|
230V/0.85Un-1.1Un
|
|
|
Nominal Frequency/Range
|
50/60Hz
|
|
|
Extended Frequency/Range
|
45-55Hz/55-65Hz
|
|
|
Power Factor
|
﹥0.99
|
|
|
Maximum units per branch
|
3
|
|
|
Efficiency
|
|
|
|
CEC Weighted Efficiency
|
95%
|
|
|
Peak Inverter Efficiency
|
96.50%
|
|
|
Static MPPT Efficiency
|
99.00%
|
|
|
Night Time Power Consumption
|
50mW
|
|
|
Mechanical Data
|
|
|
|
Ambient Temperature Range
|
-40~65℃
|
|
|
Size(mm)
|
267Wx300Hx42D(without mounting brack and cable)
|
|
|
Weight(kg)
|
5.2
|
|
|
Cooling
|
Natural cooling
|
|
|
Enclosure Environmental Rating
|
IP67
|
|
|
Features
|
|
|
|
Compatibility
|
Compatible with 60-72 cell PV modules
|
|
|
Communication
|
Power line/WIFI/Zigbee
|
|
|
Grid Connection Standard
|
EN50549-1, VDE0126-1-1, VDE 4105, ABNT NBR 16149, ABNT NBR 16150, ABNT NBR 62116, RD1699, UNE 206006 IN, UNE 206007-1 IN, IEEE1547
|
|
|
Safety EMC/Standard
|
UL 1741, IEC62109-1/-2, IEC61000-6-3, IEC61000-3-2, IEC61000-3-3
|
|
|
Warranty
|
10 years
|
|
