Yantai Boxin International Trading Co., Ltd. is a professional comprehensive trading service provider for communication equipment.With warehouses established in Yantai and Hong Kong, we have built a complete and localized network for delivering communication products and services.In 2018, Yantai Boxin International Trading Co., Ltd. set up its international sales department in Yantai, China.Based in China, we operate in emerging markets across Southeast Asia, India, the Middle East, Africa, Europe, and the United States.
Yantai Boxin International Trading Co., Ltd. supplies products to various telecom operators, meeting their needs for supplementing and expanding 2G/3G/4G/5G network stations.Our current equipment portfolio covers brands such as Nokia, Ericsson, Alcatel, Huawei, ZTE, ZTT, and FiberHome.
We expand our international market share by offering high-quality products, excellent service, competitive pricing, and timely delivery.Feel free to contact us for more information.
Electrical Specifications | ||||
Frequency Range(MHz) | 698-960 | 1710-2700 | ||
Gain(dBi) | 2.0 | 3.0 | ||
VSWR. | ≤2.0 | ≤1.5 | ||
Polarization | Vertical | |||
PIM, 3rd Order, 2x20W(dBc) | ≤-140| -150| -153 | |||
Horizontal Beam width | 360° | |||
Vertical Beam width | 80° | 38° | ||
Input Impedance | 50 Ω | |||
Max.Input Power | 50 W | |||
Lightning Protection | DC Ground | |||
Mechanical Specifications | ||||
Connector | N| 4.3-10 Female | |||
Dimensions(mm) | Ø204x129 | |||
Weight(kg) | 0.4 | |||
Radome Material | ABS | |||
Operating Temperature | -40°C to +65 °C | |||
Mounting | Ceiling Mount | |||
Yantai Boxin International Trade Co., Ltd.
Click the number to chat on WhatsApp or send an email. WeChat ID is the same as the phone number.
Yantai Boxin International Trading Co., Ltd. is a professional comprehensive trading service provider for communication equipment.With warehouses established in Yantai and Hong Kong, we have built a complete and localized network for delivering communication products and services.In 2018, Yantai Boxin International Trading Co., Ltd. set up its international sales department in Yantai, China.Based in China, we operate in emerging markets across Southeast Asia, India, the Middle East, Africa, Europe, and the United States.
Yantai Boxin International Trading Co., Ltd. supplies products to various telecom operators, meeting their needs for supplementing and expanding 2G/3G/4G/5G network stations.Our current equipment portfolio covers brands such as Nokia, Ericsson, Alcatel, Huawei, ZTE, ZTT, and FiberHome.
We expand our international market share by offering high-quality products, excellent service, competitive pricing, and timely delivery.Feel free to contact us for more information.
Electrical Specifications | ||||
Frequency Range(MHz) | 698-960 | 1710-2700 | ||
Gain(dBi) | 2.0 | 3.0 | ||
VSWR. | ≤2.0 | ≤1.5 | ||
Polarization | Vertical | |||
PIM, 3rd Order, 2x20W(dBc) | ≤-140| -150| -153 | |||
Horizontal Beam width | 360° | |||
Vertical Beam width | 80° | 38° | ||
Input Impedance | 50 Ω | |||
Max.Input Power | 50 W | |||
Lightning Protection | DC Ground | |||
Mechanical Specifications | ||||
Connector | N| 4.3-10 Female | |||
Dimensions(mm) | Ø204x129 | |||
Weight(kg) | 0.4 | |||
Radome Material | ABS | |||
Operating Temperature | -40°C to +65 °C | |||
Mounting | Ceiling Mount | |||
Yantai Boxin International Trade Co., Ltd.
برای گفتگو در واتساپ روی شماره کلیک کنید یا ایمیل بفرستید. شناسه ویچت با شماره تلفن یکسان است.
Supports 2G/3G/4G/5G frequency bands. Detailed band specifications depend on the specific model and configuration. Contact our sales team for the exact band coverage of your target market.
Standard telecom interfaces including optical ports, RF connectors, Ethernet ports and power interfaces. Connector types and quantities vary by product model. Full interface specifications available in the product datasheet.
Operating voltage range, power consumption and power supply requirements differ by equipment type. Typical operating temperature range: -40°C to +55°C. Detailed power specifications provided on request.
Products comply with CE, RoHS, FCC and ISO 9001 standards where applicable. Certification documents and test reports are available for verified B2B customers upon request.
Compatible with major telecom infrastructure vendors. Suitable for indoor and outdoor deployment scenarios including base stations, transmission nodes and optical distribution networks. Custom configurations available for large-scale projects.
Need this product in volume? Contact our sales team for competitive B2B pricing, customization options and shipping arrangements. We respond within 24 hours.این محصول را بهصورت عمده نیاز دارید؟ برای قیمت رقابتی B2B، سفارشیسازی و حمل با تیم فروش تماس بگیرید. ظرف ۲۴ ساعت پاسخ میدهیم.
