Network Smooth Upgrade Huawei OSN9800 TNU1N401P 200G Wavelength Division Board Cali Old Compatible Plug and Play

Yantai Boxin International Trading Co., Ltd. is a professional comprehensive trading service provider for communication equipment.With warehouses established in Yantai and Hong Kong, we have built a complete and localized network for delivering communication products and services.In 2018, Yantai Boxin International Trading Co., Ltd. set up its international sales department in Yantai, China.Based in China, we operate in emerging markets across Southeast Asia, India, the Middle East, Africa, Europe, and the United States.

Yantai Boxin International Trading Co., Ltd. supplies products to various telecom operators, meeting their needs for supplementing and expanding 2G/3G/4G/5G network stations.Our current equipment portfolio covers brands such as Nokia, Ericsson, Alcatel, Huawei, ZTE, ZTT, and FiberHome.

We expand our international market share by offering high-quality products, excellent service, competitive pricing, and timely delivery.Feel free to contact us for more information.

Product Description

1.Product Overview

TNU1N401P is a standard economical single wave 200G coherent wavelength division multiplexing circuit board on the Huawei OSN 9800 series optical transmission platform.This board is based on Huawei's mature 200G transmission technology platform, focusing on providing stable, reliable, and cost-effective basic 200G line side transmission capabilities.It is positioned in scenarios that are cost sensitive but require telecom grade reliability in the network.It is an ideal choice for users to smoothly evolve from 100G networks to 200G, or to build an economical 200G transmission layer.It is particularly suitable for applications such as metropolitan aggregation, regional trunk expansion, and enterprise dedicated line carrying.

2.Core Features and Value Positioning

High cost-effective 200G transmission solution

On the basis of ensuring core transmission performance, better cost control has been achieved through optimized design, providing customers with highly competitive transmission costs per bit.

It is an economical and efficient choice to build a large-scale 200G network and double the capacity (compared to 100G).

Mature and stable transmission performance

Inheriting and optimizing Huawei's widely deployed and validated 200G coherent transmission technology, it has excellent stability and reliability.

Support basic software configurable modulation formats (typically DP-QPSK, may support DP-8QAM) to adapt to different transmission distance requirements and ensure stable operation in the target application scenario.

Standardization and easy integration

Strictly following industry standards, supporting standard OTN (G.709) mapping and encapsulation, and seamlessly integrating into existing OSN9800 systems and network management systems.

The design is simple, compatible with the platform, and the installation and activation process is standardized, reducing the complexity of deployment and operation.

Smooth evolutionary path

As a basic 200G member of the OSN9800 platform, it can be mixed with earlier 100G cards and more advanced 400G/800G cards in the platform to form a network, supporting phased and on-demand expansion of the network according to business growth and investment planning.

3.Detailed technical specifications

1.Physical and General Specifications

Model: TNU1N401P

Applicable platform: Huawei OSN 9800 series subrack

Board type: Standard Economy 200G Coherent Line Interface Board

Typical power consumption:<90W

Working temperature: -5°C to+55°C

Optical module type: Supports CFP2 coherent optical module

2.Line side transmission performance

Line speed: 200G

Modulation format: Typically supports DP-QPSK (to ensure long-distance transmission), some versions or configurations may support DP-8QAM (to optimize mid-range capacity).

Line side optical interface: Supports CFP2 coherent optical modules.

Working band: C-band

Typical relay free transmission distance (based on DP-QPSK, G.652 fiber):

≥ 1000 km (meeting the transmission needs of most regions and trunk lines)

Receiver sensitivity (typical, DP-QPSK): meets the standard 200G transmission requirements, ensuring sufficient system power budget.

3.Customer side and business characteristics

Customer side connection: Connected to an independent customer side business processing board through the system backplane.

Support customer side protocols: support 100GE, 40GE, 10GE, OTU4, OTU2, etc.through the business board.

Carrying characteristics: Supports standard OTN mapping to achieve reliable carrying of customer business to line wavelength.

4.Management and Operations

Standard Network Management: Supports unified fault, configuration, and performance management through Huawei iManager U2000/NCE series network management.

Basic monitoring: Provide monitoring and alarm for key performance indicators such as optical power, center wavelength, and bit error rate.

Easy to maintain: Supports universal diagnostic and maintenance commands, with low operational barriers.

4.Typical application scenarios

Expansion of metropolitan optical network aggregation layer: used to upgrade the capacity of the metropolitan aggregation ring and cope with the traffic growth brought by 5G base station backhaul, enterprise cloud migration and other businesses with higher cost-effectiveness.

Provincial/regional economic trunk lines: Construct highly reliable and high-capacity 200G transmission planes between adjacent cities or within economic circles, balancing performance and investment.

Existing 100G network upgrade: In the deployed 100G system, selectively replace or add 200G cards to increase the capacity of critical links.

Large enterprise dedicated line network: a cross regional dedicated line network built by enterprises or provided by operators, providing stable and cost-effective 200G backbone transmission channels.

5.Summary of Core Values

Cost optimal: Minimize customer's initial investment (CAPEX) and operating costs while meeting 200G transmission requirements.

Stable and reliable: Based on a mature platform, with low technical risks, it can ensure long-term stable operation of the business.

Quick deployment: Standardized design and good compatibility make network deployment and business activation fast and easy.

Investment protection: As a standardized product, it integrates into Huawei's overall platform evolution route to ensure the long-term investment value of customers.

6.Ordering and Deployment Instructions

Basic board model: TNU1N401P.

It needs to be used in conjunction with the designated model of CFP2 coherent optical module.

Before deployment, it is recommended to calculate the optical power budget to ensure that the system performance meets the standard within the target transmission distance.

Provide standard technical support and warranty services. For complex networking applications, it is recommended to consult detailed technical solutions
