OSN8800 LSX TN11LSX TN12LSX TN13LSX TN14LSX 10 Gbit/s Wavelength Conversion Board

Yantai Boxin International Trading Co., Ltd. is a professional comprehensive trading service provider for communication equipment.With warehouses established in Yantai and Hong Kong, we have built a complete and localized network for delivering communication products and services.In 2018, Yantai Boxin International Trading Co., Ltd. set up its international sales department in Yantai, China.Based in China, we operate in emerging markets across Southeast Asia, India, the Middle East, Africa, Europe, and the United States.

Yantai Boxin International Trading Co., Ltd. supplies products to various telecom operators, meeting their needs for supplementing and expanding 2G/3G/4G/5G network stations.Our current equipment portfolio covers brands such as Nokia, Ericsson, Alcatel, Huawei, ZTE, ZTT, and FiberHome.

We expand our international market share by offering high-quality products, excellent service, competitive pricing, and timely delivery.Feel free to contact us for more information.

Product Description

1.Product Overview

Table 1: Basic Identification and Specifications

Attribute specification description

OptiX OSN 9800 series intelligent optical transmission platform

Module Name: 400G Extended Tunable Digital Coherent Optical Module (QSFP-DD Package, Ultra Long Range Enhanced Edition)

Module type QSFP-DD digital coherent optical module

Functional positioning: 400G line side wavelength conversion and transmission, optimized for ultra long distances and complex links

Physical dimensions comply with QSFP-DD MSA standard packaging

Adaptation board for OSN 9800 TN series 400G circuit board supporting QSFP-DD interface

Working temperature extension level: 0°C to+75°C (module shell temperature)

The power demand is supplied by the host board through the QSFP-DD interface, with a typical power consumption of less than 20W

Interface type: Dual LC single-mode fiber interface

Key features include ultra long distance transmission, ultra-high receiving sensitivity, strong environmental adaptability, and intelligent link optimization

2.Optical interface and transmission characteristics

Table 2: Key Optical Layer Parameters

Parameter specifications

Line speed 400 Gbit/s

Modulation Format Enhanced Probability Shape-16QAM (E-PCS-16QAM)

Optional modulation formats can be software switched to enhanced PS-8QAM and PS-QPSK modes

Adjustable wavelength range in the entire C-band (191.35 THz to 196.10 THz)

Wavelength tuning accuracy ± 0.3 GHz

Output optical power -2 dBm to+3 dBm (adjustable by software)

Receiving sensitivity ≤ -10.5 dBm (under BER=2E-2, FEC pre threshold conditions, in E-PCS-16QAM mode)

Receiving sensitivity ≤ -13.0 dBm (under BER=2E-2, FEC pre threshold conditions, PS-8QAM mode)

Receiving sensitivity ≤ -15.5 dBm (under BER=2E-2, FEC pre threshold conditions, PS-QPSK mode)

Optical signal-to-noise ratio tolerance ≤ 11.5 dB @ 0.1nm RBW (E-PCS-16QAM mode)

Optical signal-to-noise ratio tolerance ≤ 8.5 dB @ 0.1nm RBW (PS-8QAM mode)

Optical signal-to-noise ratio tolerance ≤ 6.0 dB @ 0.1nm RBW (PS-QPSK mode)

3.Core Enhancement Technology

Table 3: Ultra Long Range and Complex Link Enhancement Technologies

Technical characteristics, technical specifications, performance advantages

The ultimate receiver sensitivity optimization adopts ultra-low noise photoelectric conversion front-end and high-precision clock data recovery circuit.The receiver sensitivity is increased by 1.0-1.5dB compared to the standard 400G module, which is the core of extending the distance

The third-generation ultra strong error correction coding uses cascaded soft decision FEC (such as LDP+RS) with gain>12.5dB, which can still reliably decode at extremely low OSNR, breaking the Shannon limit of traditional FEC

The adaptive nonlinear damage engine AI assisted nonlinear digital compensation can learn and pre compensate for the nonlinear characteristics of specific links, significantly improving the transmission performance on deployed, multi span, and nonlinear complex existing fiber optic networks

Wide temperature range high-performance locked laser and DSP algorithm optimized for a wide temperature range of -5 °C to +75 °C, with minimal performance fluctuations to ensure stable performance in extreme weather conditions or poorly ventilated computer rooms, reducing operational intervention

4.Transmission performance indicators

Table 4: Transmission Distance and System Performance (Typical Values)

Performance indicators E-PCS-16QAM mode PS-8QAM mode PS-QPSK mode

Non electric relay transmission distance (G.652.D) 800-1000 km 1200-1500 km 1800-2200 km

OSNR requires (@ 0.1nm, FEC threshold) of approximately 14.0 dB, approximately 10.5 dB, and approximately 7.5 dB

Dispersion tolerance (fully compensated)>± 50000 ps/nm>± 55000 ps/nm>± 60000 ps/nm

Polarization mode dispersion tolerance>25 ps>30 ps>35 ps

Performance Temperature Coefficient OSNR Tolerance Change<0.3 dB/10°C OSNR Tolerance Change<0.2 dB/10°C OSNR Tolerance Change<0.15 dB/10°C

5.Intelligent management and optimization functions

Table 5: Intelligent Link Optimization and Monitoring

Function category Function description Operation and maintenance value

After the link feature learning and modeling module is launched, it automatically conducts multiple rounds of testing to learn the loss, nonlinearity, and PMD characteristics of the current fiber optic link and establish a digital model.Implement"one click optimal configuration", automatically recommend the most suitable modulation format, transmission power and other parameters for the link, simplify the start.

Performance dynamic fine-tuning: Continuously monitor performance during operation and fine tune DSP parameters (such as equalizer tap coefficients, NLC strength) to track slow changes in the link.Resist slow performance drift caused by fiber aging, environmental temperature cycle changes, etc., and maintain long-term optimal performance.

Cross segment damage distribution assessment combined with transmission and reception signal analysis to evaluate the accumulation of nonlinear damage in each segment of the link.Provide guidance for network optimization, such as identifying specific spans where optical amplifier power needs to be adjusted.

Prefabricated fault simulation supports initiating simulation tests in network management to predict performance changes if switching to other modulation formats or adjusting power.Support lossless business optimization exercises and expansion planning to reduce operational risks in the current network.

6.Application scenarios

Table 6: Typical Application Scenarios

The core problems and advantages solved by the application scenario recommendation mode

The 400G backbone network PS-8QAM/PS-QPSK achieves nationwide 400G trunk coverage of over 1200km, achieving the ultimate balance between single wave capacity and distance, and reducing the number of electric regeneration relay stations.

The extended PS-QPSK of the transoceanic submarine cable meets the requirements of ultra long distance, large capacity, and high reliability connection from the submarine cable landing station to the inland core data center.

The complex network smooth upgrade adaptive mode is successfully inserted and transmitted over a long distance of 400G new wavelength on existing optical fibers with a large number of 100G/200G services without changing the optical amplifier configuration.

The high latitude/desert mainline arbitrary mode, with its excellent wide temperature stability, operates stably in extreme climate regions such as Russia, Canada, and the Middle East.

7.Compatibility and configuration requirements

Table 7: System Compatibility Requirements

Specific description of the required category

The host board and software host board must be high-performance 400G line cards, and the device software and network management must support their intelligent tuning features and enhanced FEC.

The basic requirements for optical links are that although they have strong performance, fiber optic links still need to have a basic OSNR foundation.It is recommended to use G.654.E fiber optic in ultra long distance scenarios.

It is strongly recommended to use its"automatic link learning" function for the opening process, rather than manual configuration, to achieve optimal performance.

It can be mixed with traditional modules and standard 400G modules in the same fiber, but its optimal transmission power may be different and needs to be optimized uniformly at the system level.

8, Maintenance and ordering information

Table 8: Maintenance and Ordering Points

Project Information

Component code TN13LSX

The technical positioning is a"flagship" or"special" solution for the most demanding long-distance scenarios at a speed level of 400G.

From the perspective of total cost of ownership, its high unit price may be offset by factors such as reduced number of electrical relay stations, fiber core savings from higher single wave capacity, and lower long-term operation and maintenance costs.

When the transmission distance requirement exceeds 600 kilometers (16QAM) or 1000 kilometers (8QAM) and the standard module cannot meet it, TN13LSX should be considered as the selection decision point.

Core Summary:

TN13LSX is an engineering masterpiece that pushes 400G technology to the"distance limit".It represents the highest balance point that can be achieved between capacity, distance, and adaptability to complex environments in the field of pluggable coherent optical modules.

Core values:

Breaking the distance barrier: enabling reliable transmission of 400G signals over thousands of kilometers, truly expanding its application scenarios from urban/regional backbone to national and even international trunk lines.

Intelligent breakthrough: Through intelligent functions such as"link learning" and"dynamic fine-tuning", the technical threshold and risk of deploying 400G in ultra long distance and complex existing networks have been significantly reduced.

Facing the current network and the future: Its strong environmental adaptability and tolerance for old fiber optic cables protect the existing fiber optic assets of operators, paving the way for the smooth evolution of the network towards 400G and even higher speeds.

The core difference from TN13LQM (standard type):

TN13LQM is a " mainstream balanced " product suitable for most 400G scenarios. TN13LSX is a " breakthrough " product designed for specific challenging scenarios where distance, environment, or current network conditions push ordinary 400G modules to the edge of performance. Choosing TN13LSX means you have chosen a complete high-performance solution that includes cutting-edge hardware, intelligent algorithms, and professional deployment methods.
