TNU5N501P is a cutting-edge ultra high speed wavelength division multiplexing circuit board for the OSN 9800 series optical transmission platform, aimed at the future.This board has achieved a breakthrough line rate of 1.6T (1600G) per wave, marking a new era of capacity for optical transmission technology.It integrates Huawei's top research achievements in photon integration, ultra-high baud rate, advanced modulation and signal processing, and is designed specifically for the next-generation global core backbone network, strategic computing hub interconnection, and cutting-edge experimental networks for future businesses such as 6G and metaverse.TNU5N501P is not only a product, but also a symbol of Huawei's technological leadership, aimed at solving the ultimate capacity challenge brought by exponential data growth to basic networks.

2.Core Features and Breakthrough Technologies

Single wave 1.6T: Defining the Next Generation Capacity Standard

Realizing a single channel transmission capacity of 1.6Tbps and elevating the single wavelength capacity to a whole new level is the core engine for building single fiber 100T or even hundreds of T systems.

This breakthrough provides a clear technological path and capacity reserve for the bandwidth demand in the next decade or even longer.

Revolutionary ultra-high frequency spectral efficiency technology

Adopting industry-leading ultra-high baud rates (such as>200 GBaud) combined with ultra-high order multidimensional modulation technology, and incorporating artificial intelligence enabled nonlinear compensation and probability shaping algorithms.

Achieve spectral efficiency close to theoretical limits on the extended C+L full band, maximizing the physical layer potential of optical fibers.

Super strong load-bearing and slicing capabilities for future business

Forward looking support for transparent bearer of future 1.6TbE and higher rate Ethernet services, with flexible business bundling and routing capabilities.

The integration of ultra fine hard slicing technology and deterministic delay guarantee mechanism can provide deterministic super bandwidth channels for future services such as holographic communication, industrial Internet, large-scale AI training clusters, etc.

Fully intelligent network autonomy and openness

Deeply integrated AI core, supporting optical transmission digital twin, performance self optimization and fault self-healing, achieving full lifecycle autonomy of the network.

Provide an open optical layer programmable interface (OpenConfig/YANG model) that can deeply collaborate with national level computing power scheduling platforms and scientific research network control planes to achieve intelligent scheduling of"computing network integration".

3.Detailed technical specifications

1.Physical and General Specifications

Model: TNU5N501P

Applicable platform: Huawei OSN 9800 top-level performance platform

Board type: Ultra high speed 1.6T coherent line interface board

Line speed: 1.6T

Design concept: Targeting extreme performance and cutting-edge applications, adopting innovative architecture and heat dissipation design.

2.Line side transmission performance

Core modulation and baud rate: Supports industry-leading ultra-high baud rate and programmable multi-dimensional high-order modulation format combinations.

Line side optical interface: Supports high-performance, high-density pluggable coherent optical modules optimized for 1.6T.

Working band: Complete C-band and support smooth extension to C+L full band.

Transmission performance goal: aimed at breaking through the existing limit of"capacity distance spectrum efficiency" and supporting long-distance transmission at the backbone network level at ultra-high speeds:

Target distance: ≥600 km (regional backbone and core interconnection)

Target spectral efficiency:>10 bits/s/Hz (achieved on C+L band system)

3.Customer side and business characteristics

Customer side interface: Through the next-generation backplane interconnect architecture with ultra-high bandwidth and ultra-low latency.

Support business interfaces: oriented towards future standards, supporting Nx800GE, 1.6TbE (future), OTUCn and other interfaces.

Key feature: Supports flexible slicing, binding, and load balancing for ultra large scale business flows.

4.Management and Operations

Intent driven network: As the core execution unit of Huawei iMaster NCE's"autonomous driving network", it supports automatic translation and execution of business intent.

Full stack visualization and predictability: providing a full stack digital twin from the photophysical layer to the business layer, enabling early prediction and avoidance of performance degradation.

Open Programmable: Provides an open optical layer API for scientific research and innovation, supporting custom transmission experiments and verification of new protocols.

4.Typical application scenarios

The core of next-generation information infrastructure: as the ultimate capacity core of upgraded or future information highways, it carries strategic data circulation.

Global interconnection of scientific research facilities: connecting globally distributed large scientific devices such as the Square Kilometer Array Radio Telescope (SKA) and the Next Generation High Energy Physics Collider, achieving real-time aggregation and processing of massive experimental data.

A testbed for 6G and metaverse: providing a bottom layer network verification and hosting platform for the ultra-high bandwidth and ultra-low latency required for the integrated network of 6G, space, earth, and sea, as well as the immersive experience of metaverse.

Future interconnection between top cloud service providers and supercomputing centers: meeting the long-term demand for EB level data exchange between next-generation AI computing power clusters and quantum computing centers.

5.Summary of Core Values

Technological high ground: The 1.6T single wave rate sets a new benchmark for global optical transmission technology and establishes a long-term technological advantage.

Facing future business: providing a solid"network foundation" for disruptive applications that have not yet been born but will inevitably emerge, such as holographic communication and brain computer interface networks.

Intergenerational Network Crossing: Helping customers bridge the existing generation gap and directly build future oriented high-speed and intelligent network infrastructure.

Strategic investment value: not only network equipment, but also strategic investment to participate in and lead the development of future digital society.

6.Ordering and Deployment Instructions

Basic board model: TNU5N501P.

This product adopts the"joint innovation and strategic cooperation" model, usually targeting top projects, top research institutions, and strategic partners, requiring in-depth technical docking and joint planning.

Collaborative deployment of a complete set of cutting-edge optical layer solutions, such as ultra wideband amplifiers and intelligent optical switching matrices.

Provide comprehensive top-level services supported by a team of top experts, covering strategic consulting, joint research and development, systems engineering, and long-term evolution.
