COP-SI800G-LR8 800G OSFP Optical Transceiver SMF OSFP 800G 2*DR4 G.652/G.652.D 10Km COP-SI800G-LR8
1601723638236_COP-SI800G-LR8The 800G and 400G optical transceivers are high-speed fiber-optic modules used to transmit large volumes of data over fiber optics.Their usage is mainly driven by the need formassive bandwidth, low latency, and scalabilityin modern networks, likedata centers, AI Computing Cluster, Data Center Interconnect, Internal Fabric.
| Package | Part No. | Fiber Type | Data Rate | Case Temperature | Cable Specifications | Distance | DDM |
| 800G OSFP | COP-85800G-SR8 | MMF | 800G | Com. | OM3/OM4 | 1-100m | yes |
| COP-SI800G-DR8 | SMF | 800G | Com. | G.652/G.652.D | 500m | yes | |
| COP-SI800G-FR8 | SMF | 800G | Com. | G.652/G.652.D | 2km | yes | |
| COP-SI800G-LR8 | SMF | 800G | Com. | G.652/G.652.D | 10km | yes | |
| 400G OSFP | COP-85400G-SR4 | MMF | 400G | Com. | OM3/OM4 | 1-100m | yes |
| COP-SI400G-DR4 | SMF | 400G | Com. | G.652/G.652.D | 500m | yes | |
| COP-SI400G-FR4 | SMF | 400G | Com. | G.652/G.652.D | 2km | yes | |
| COP-SI400G-LR4 | SMF | 400G | Com. | G.652/G.652.D | 10km | yes | |
| 800G QSFP-DD | CQP-85800G-SR8 | MMF | 800G | Com. | OM3/OM4 | 1-100m | yes |
| CQP-SI800G-DR8 | SMF | 800G | Com. | G.652/G.652.D | 500m | yes | |
| CQP-SI800G-FR8 | SMF | 800G | Com. | G.652/G.652.D | 2km | yes | |
| CQP-SI800G-LR8 | SMF | 800G | Com. | G.652/G.652.D | 10km | yes | |
| 400G QSFP-DD | CQP-85400G-SR4 | MMF | 400G | Com. | OM3/OM4 | 1-100m | yes |
| CQP-SI400G-DR4 | SMF | 400G | Com. | G.652/G.652.D | 500m | yes | |
| CQP-SI400G-FR4 | SMF | 400G | Com. | G.652/G.652.D | 2km | yes | |
| CQP-S1400G-LR4 | SMF | 400G | Com. | G.652/G.652.D | 10km | yes |
| Package | Part No. | Fiber Type | Data Rate | Case Temperature | Cable specifications | Distance |
| 800G OSFP | COP-DAC800G-01C | Cable | 800G to 800G | Com. | AWG 30 | 1m |
| 800G OSFP | COP-DAC800G-02C | Cable | 800G to 800G | Com. | AWG 28 | 2m |
| 800G OSFP | COP-2DAC800G-01C | Cable | 800G to 2*400G | Com. | AWG 30 | 1m |
| 800G OSFP | COP-2DAC800G-02C | Cable | 800G to 2*400G | Com. | AWG 28 | 2m |
| 800G QSFP DD | CQD-DAC800G-01C | Cable | 800G to 800G | Com. | AWG 30 | 1m |
| 800G QSFP DD | CQD-DAC800G-02C | Cable | 800G to 800G | Com. | AWG 28 | 2m |
| 800G QSFP DD | CQD-2DAC800G-01C | Cable | 800G to 2*400G | Com. | AWG 30 | 1m |
| 800G QSFP DD | CQD-2DAC800G-02C | Cable | 800G to 2*400G | Com. | AWG 28 | 2m |
| 400G OSFP | COP-DAC400G-01C | Cable | 400G to 400G | Com. | AWG 30 | 1m |
| 400G OSFP | COP-DAC400G-02C | Cable | 400G to 400G | Com. | AWG 28 | 2m |
| 400G OSFP | COP-2DAC400G-01C | Cable | 400G is 2*200G | Com. | AWG 30 | 1m |
| 400G OSFP | COP-2DAC400G-02C | Cable | 400G is 2*200G | Com. | AWG 28 | 2m |
| 400G QSFP DD | CQD-DAC400G-01C | Cable | 400G to 400G | Com. | AWG 30 | 1m |
| 400G QSFP DD | CQD-DAC400G-02C | Cable | 400G to 400G | Com. | AWG 28 | 2m |
| 400G QSFP DD | CQD-2DAC400G-01C | Cable | 400G is 2*200G | Com. | AWG 30 | 1m |
| 400G QSFP DD | CQD-2DAC400G-02C | Cable | 400G is 2*200G | Com. | AWG 28 | 2m |
| Connector Type | Core | Fiber Type | Material | Insertion Loss | Return loss | Ref Picture |
| MTP/APC-MTP/APC | 2008/12/24 | MMF | LSZH | <0.35dB | >20dB |  |
| MTP/UPC-MTP/UPC | ||||||
| MTP/UPC-LC/UPC | 2008/12/24 | MMF | LSZH | <0.35dB | >60dB |  |
| MTP/UPC-LC/APC | ||||||
| MTP/UPC-MTP/UPC | 2008/12/24 | SMF | LSZH | <0.35dB | >60dB |  |
| MTP/APC-MTP/APC | ||||||
| MTP/UPC-LC/UPC | 2008/12/24 | MMF/SMF | LSZH | <0.35dB | >60dB |  |
| MTP/UPC-LC/APC |
| LC/APC LC/APC | Single/Dual core | MMF/SMF | LSZH | <0.35dB | >60dB |  |
| SC/UPC SC/UPC | Single/Dual core | MMF/SMF | LSZH | <0.35dB | >60dB |  |
| SC/APC SC/UPC | Single/Dual core | MMF/SMF | LSZH | <0.35dB | >60dB |  |
| SC/APC SC/APC | Single/Dual core | MMF/SMF | LSZH | <0.35dB | >60dB |  |
Contáctenos
Yantai Boxin International Trade Co., Ltd.
Haga clic en el número para chatear por WhatsApp o envíe un correo. El ID de WeChat es el mismo que el teléfono.
Especificaciones técnicas
Frecuencia y bandas
Supports 2G/3G/4G/5G frequency bands. Detailed band specifications depend on the specific model and configuration. Contact our sales team for the exact band coverage of your target market.
Interfaces y conectores
Standard telecom interfaces including optical ports, RF connectors, Ethernet ports and power interfaces. Connector types and quantities vary by product model. Full interface specifications available in the product datasheet.
Alimentación y consumo
Operating voltage range, power consumption and power supply requirements differ by equipment type. Typical operating temperature range: -40°C to +55°C. Detailed power specifications provided on request.
Certificaciones y cumplimiento
Products comply with CE, RoHS, FCC and ISO 9001 standards where applicable. Certification documents and test reports are available for verified B2B customers upon request.
Compatibilidad e implementación
Compatible with major telecom infrastructure vendors. Suitable for indoor and outdoor deployment scenarios including base stations, transmission nodes and optical distribution networks. Custom configurations available for large-scale projects.
