02314BDD SFP-1000BaseT-G2 Electrical Transceiver,SFP,GE,Electrical Interface Module(100m,RJ45) for CloudEngine S16700 Series
$200.00 USD
Quantité
Yantai Boxin International Trading Co., Ltd. is a professional comprehensive trading service provider for communication equipment.With warehouses established in Yantai and Hong Kong, we have built a complete and localized network for delivering communication products and services.In 2018, Yantai Boxin International Trading Co., Ltd. set up its international sales department in Yantai, China.Based in China, we operate in emerging markets across Southeast Asia, India, the Middle East, Africa, Europe, and the United States.
Yantai Boxin International Trading Co., Ltd. supplies products to various telecom operators, meeting their needs for supplementing and expanding 2G/3G/4G/5G network stations.Our current equipment portfolio covers brands such as Nokia, Ericsson, Alcatel, Huawei, ZTE, ZTT, and FiberHome.
We expand our international market share by offering high-quality products, excellent service, competitive pricing, and timely delivery.Feel free to contact us for more information.
Description du produit
S16700 Introduction
CloudEngine S16700 series switches (S16700 for short) are next-generation modular core switches designed for high-end campus networks in the all-wireless era. S16700 series switches consist of two models with four Line Processing Unit (LPU) slots and eight LPU slots respectively. They provide ultra-high-density full-rate access ports, meeting customers& # 39; requirements for quickly building campus networks with simplified architecture. S16700 series switches use Huawei& # 39;s next-generation converged software platform to provide customers with a trusted platform system and secure data access. Key components, such as main control boards, power modules, and fan modules, adopt redundancy design to provide carrier-class reliability. The switches are ideal aggregation and access nodes for building cloud campus networks, helping global customers achieve their digital transformation goals.
|
Spécifications techniques
|
S16700-4
|
S16700-8
|
|
Height [mm]
|
438 mm
|
703 mm
|
|
Depth [mm]
|
874 mm
|
874 mm
|
|
Width [mm]
|
442 mm
|
442 mm
|
|
Chassis height [U]
|
9.8
|
15.8
|
|
Weight without packaging
|
94.1 (207.45)
|
129.8 (286.16)
|
|
Weight with packaging
|
138 (304.23)
|
177 (390.21)
|
|
Maximum power consumption [W]
|
4664
|
8260
|
|
Heat dissipation mode
|
Drawing air for heat dissipation
|
Drawing air for heat dissipation
|
|
Maximum heat dissipation [BTU/h]
|
15914
|
28183
|
|
Input voltage range [V]
|
AC: 220 V; 50 Hz/60 Hz
High-voltage DC (HVDC): 240 V/380 V |
AC: 176 V to 290 V; 45 Hz to 65 Hz
High-voltage DC (HVDC): 188 V to 288 V or 260 V to 400 V |
|
Rated input voltage [V]
|
AC: 176 V to 290 V; 45 Hz to 65 Hz
High-voltage DC (HVDC): 188 V to 288 V or 260 V to 400 V |
AC: 220 V; 50 Hz/60 Hz
High-voltage DC (HVDC): 240 V/380 V |
|
Number of MPU slots
|
2
|
2
|
|
Number of power slots
|
6
|
10
|
|
Number of service board slots
|
4
|
8
|
|
Number of SFU slots
|
9
|
9
|
|
Redundant Switch fabrics
|
N+M
|
N+M
|
|
Redundant power supply
|
Dual-input power supply system: N+1 backup is recommended.
Single-input power supply system: N+1 backup Dual-input power supply is recommended to ensure reliability. |
Dual-input power supply system: N+1 backup is recommended.
Single-input power supply system: N+1 backup Dual-input power supply is recommended to ensure reliability. |
|
Redundant MPUs
|
1:01
|
1:01
|
|
Redundant fans
|
Fan modules work in hot standby mode.At the normal temperature range, the system can operate properly for a short time after a
single fan module fails.You are advised to replace the faulty fan module immediately. |
Fan modules work in hot standby mode.At the normal temperature range, the system can operate properly for a short time after a
single fan module fails.You are advised to replace the faulty fan module immediately. |
|
Automatic fan speed adjustment
|
Supported
|
Supported
|
|
Airflow direction
|
Front-to-rear airflow
|
Front-to-rear airflow
|
|
Long-term operating temperature
|
0°C to 40°C (32°F to 140°F)
|
0°C to 40°C (32°F to 140°F)
|
|
Storage temperature
|
–40°C to +70°C (–40°F to +158°F)
|
–40°C to +70°C (–40°F to +158°F)
|
|
Restriction on the operating temperature variation rate
|
When the altitude is 1800 m to 5000 m (5905.44 ft. to 16404.00 ft.), the highest operating temperature reduces by 1°C (1.8°F)
every time the altitude increases by 220 m (722 ft.). |
When the altitude is 1800 m to 5000 m (5905.44 ft. to 16404.00 ft.), the highest operating temperature reduces by 1°C (1.8°F)
every time the altitude increases by 220 m (722 ft.). |
|
Long-term operating relative humidity [RH]
|
5% RH to 85% RH (non-condensing)
|
5% RH to 85% RH (non-condensing)
|
|
Long-term operating altitude
|
≤ 5000 m (16404 ft.)
|
≤ 5000 m (16404 ft.)
|
|
Storage altitude
|
≤ 5000 m (16404 ft.)
|
≤ 5000 m (16404 ft.)
|
|
MTBF [year]
|
34.93
|
34.55
|
|
MTTR [h]
|
1
|
1
|
|
Availability
|
0.99999717
|
0.999997158
|
|
Maximum number of 100GE ports
|
144
|
288
|
|
Maximum number of 40GE ports
|
144
|
288
|
|
Maximum number of 10GE ports
|
192
|
384
|
|
Maximum number of GE ports
|
192
|
384
|
|
PoE
|
Not supported
|
Not supported
|
|
Maximum power output capability (including the system power output and PoE power output) [W]
|
5+1 backup: 3000 W x 5 = 15000 W
6+0 backup: 3000 W x 6 = 18000 W |
9+1 backup: 3000 W x 9 = 27000 W
10+0 backup: 3000 W x 10 = 30000 W |
Ordering information
The following table lists ordering information for theS16700series switches.
|
Part Number
|
Model
|
Description
|
||
|
02355HUL
|
EX1BS16704SA0
|
S16700-4 AC/HVDC assembly chassis
|
||
|
02355HUM
|
EX1BS16704SD0
|
S16700-4 DC assembly chassis
|
||
|
2122487
|
FAN-240SA-B
|
Fan Tray Assembly
|
||
|
03050KLA
|
LSH7MPUAX1T0
|
S16700 Main Processing Unit A (HTM)
|
||
|
03050JNL
|
LSH7SFUAX100
|
S16700-4 Switch Fabric Unit A (X1)
|
||
|
03050JNM
|
LSH7SFUBX100
|
S16700-4 Switch Fabric Unit B (X1)
|
||
|
2116250
|
GXRACK-A610A
|
2.2m Galaxy Assembly Cabinet-A610-22
|
||
|
2116249
|
GXRACK-A612A
|
2.2m Galaxy Assembly Cabinet-A612-22
|
||
|
02355HUN
|
EX1BS16708SA0
|
S16700-8 AC/HVDC assembly chassis
|
||
|
02355HUP
|
EX1BS16708SD0
|
S16700-8 DC assembly chassis
|
||
|
2122486
|
FAN-480SA-B
|
Fan Tray Assembly
|
||
|
03050JNN
|
LSH7SFUGX100
|
S16700-8 Switch Fabric Unit G (X1)
|
||
|
03050JNP
|
LSH7SFUHX100
|
S16700-8 Switch Fabric Unit H (X1)
|
||
|
Interface Card
|
|
|
||
|
03050JNK
|
LSH7X48SX1E0
|
48-Port 10G Optical Interface Card (X1E, SFP+)
|
||
|
03050JNJ
|
LSH7L24QX1E0
|
24-Port 40G Optical Interface Card (X1E, QSFP+)
|
||
|
03050JNH
|
LSH7L36QX1E0
|
36-Port 40G Optical Interface Card (X1E, QSFP+)
|
||
|
03050JNG
|
LSH7C18HX1E0
|
18-Port 100G Optical Interface Card (X1E, QSFP28)
|
||
|
03050JNF
|
LSH7C36HX1E0
|
36-Port 100G Optical Interface Card (X1E, QSFP28)
|
||
|
2122538
|
CR8MP2KHDCC0
|
380VDC HVDC Power Distribution Unit
|
||
|
02312JEA
|
PAH-3000WA
|
3000W Dual Inputs AC&HVDC Power Module
|
||
|
02312GDC
|
PDC-2200WC
|
PSU-PDC-2200WC-PM2200W DC Power Supply
|
||
|
2122145
|
CR5MDPD12500
|
DPD125-12-24 DC Power Distribution Box
|
||
|
2122537
|
CR8MP2K3PHC0
|
AC Power Distribution Unit
|
||
|
02354GYS
|
APD32-4-24
|
APD32-4-24 AC Power Distribution Unit
|
||
|
02354GYQ
|
APD32-12-24
|
APD32-12-24 AC Power Distribution Unit
|
||
|
02354GYV
|
APD63-2-24
|
APD63-2-24 AC Power Distribution Unit
|
||
|
02354GYT
|
APD63-6-24
|
APD63-6-24 AC Power Distribution Unit
|
||
|
Optical Transceiver
|
|
|
||
|
2314171
|
SFP-1000BaseT
|
Electrical Transceiver,SFP,GE,Electrical Interface Module(100m,RJ45)
|
||
|
02313URG
|
SFP-1000BaseT
|
Electrical Transceiver,SFP,GE,Electrical Interface Module(100m,RJ45)
|
||
|
2315204
|
eSFP-GE-SX-MM850
|
Optical Transceiver,eSFP,GE,Multi-mode Module(850nm,0.55km,LC)
|
||
|
02313URD
|
eSFP-GE-SX-MM850
|
Optical Transceiver,eSFP,GE,Multi-mode Module(850nm,0.55km,LC)
|
||
|
2315200
|
SFP-GE-LX-SM1310
|
Optical Transceiver,eSFP,GE,Single-mode Module(1310nm,10km,LC)
|
||
|
02313URF
|
SFP-GE-LX-SM1310
|
Optical Transceiver,eSFP,GE,Single-mode Module(1310nm,10km,LC)
|
||
|
2317346
|
S-SFP-GE-LH40-SM1310
|
Optical Transceiver,eSFP,GE,Single-mode Module(1310nm,40km,LC)
|
||
|
2317347
|
S-SFP-GE-LH40-SM1550
|
Optical Transceiver,eSFP,GE,Single-mode Module(1550nm,40km,LC)
|
||
|
2317348
|
S-SFP-GE-LH80-SM1550
|
Optical Transceiver,eSFP,GE,Single-mode Module(1550nm,80km,LC)
|
||
|
02314BDD
|
SFP-1000BaseT-G2
|
Electrical Transceiver,SFP,GE,Electrical Interface Module(100m,RJ45)
|
||
|
02310MNW
|
SFP-10G-USR
|
10GBase-USR Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.1km,LC)
|
||
|
02313URN
|
SFP-10G-USR
|
10GBase-USR Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.1km,LC)
|
||
|
2318169
|
OMXD30000
|
Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.3km,LC)
|
||
|
02313URC
|
OMXD30000
|
Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.3km,LC)
|
||
|
2318170
|
OSX010000
|
Optical Transceiver,SFP+,10G,Single-mode Module(1310nm,10km,LC)
|
||
|
02313URK
|
OSX010000
|
Optical Transceiver,SFP+,10G,Single-mode Module(1310nm,10km,LC)
|
||
|
02310CNF
|
OSX040N01
|
Optical Transceiver,SFP+,10G,Single-mode Module(1550nm,40km,LC)
|
||
|
02314KKG
|
OSX040N01
|
Optical Transceiver,SFP+,10G,Single-mode Module(1550nm,40km,LC)
|
||
|
02310SNN
|
SFP-10G-ZR
|
10GBase-ZR Optical Transceiver,SFP+,10G,Single-mode Module(1550nm,80km,LC)
|
||
|
02310QDJ
|
SFP-10G-LR
|
Optical Transceiver,SFP+,10G,Single-mode Module(1310nm,10km,LC)
|
||
|
02313URL
|
SFP-10G-LR
|
Optical Transceiver,SFP+,10G,Single-mode Module(1310nm,10km,LC)
|
||
|
02312UUF
|
SFP-10G-iLR-C
|
Optical Transceiver,SFP+,9.8G,Single-mode Module(1310nm,1.4km,LC)
|
||
|
02310MHR
|
QSFP-40G-iSR4
|
40GBase-iSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.15km,MPO)(connecting to one QSFP+ or four SFP+)
|
||
|
02313URW
|
QSFP-40G-iSR4
|
40GBase-iSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.15km,MPO)(connecting to one QSFP+ or four SFP+)
|
||
|
02310RMB
|
QSFP-40G-eSR4
|
40GBase-eSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.3km,MPO)(connecting to one QSFP+ or four SFP+)
|
||
|
02313URU
|
QSFP-40G-eSR4
|
40GBase-eSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.3km,MPO)(connecting to one QSFP+ or four SFP+)
|
||
|
02313NUG
|
QSFP-40G-LX4-MM
|
40GBase-LX4-MM Optical Transceiver,QSFP+,40GE,Multi-mode(1310nm,0.15km,LC)
|
||
|
02310MHS
|
QSFP-40G-LR4
|
40GBASE-LR4 optical transceiver, QSFP+, 40G, single-mode module (1310nm, 10km, LC)
|
||
|
02313URY
|
QSFP-40G-LR4
|
40GBASE-LR4 optical transceiver, QSFP+, 40G, single-mode module (1310nm, 10km, LC)
|
||
|
02311YVB
|
QSFP-40G-LR4-Lite
|
40GBase-LR4 Lite Optical Transceiver,QSFP+,40G,Single-mode Module(1310nm,2km,LC)
|
||
|
02313URS
|
QSFP-40G-LR4-Lite
|
40GBase-LR4 Lite Optical Transceiver,QSFP+,40G,Single-mode Module(1310nm,2km,LC)
|
||
|
02311MNN
|
QSFP-100G-CWDM4
|
100GBase-CWDM4 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,2km,LC)
|
||
|
02312VSP
|
QSFP28-100G-DR
|
100GBase,DR,Optical Transceiver,QSFP28,100G,Single-mode module (1311nm,0.5km,LC)
|
||
|
02311KNU
|
QSFP28-100G-LR4
|
100GBase-LR4 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,10km,LC)
|
||
|
02313URT
|
QSFP28-100G-LR4
|
100GBase-LR4 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,10km,LC)
|
||
|
02311GBW
|
QSFP28-100G-SR4
|
100GBase-SR4 Optical Transceiver, QSFP28, 100G, Multi-mode (850nm, 0.1km, MPO)
|
||
|
02313URQ
|
QSFP28-100G-SR4
|
100GBase-SR4 Optical Transceiver, QSFP28, 100G, Multi-mode (850nm, 0.1km, MPO)
|
||
|
02311MNM
|
QSFP28-100G-PSM4
|
100GBase-PSM4 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,0.5km,MPO)
|
||
|
02311QUK
|
QSFP-100G-SWDM4
|
100GBase-SWDM4 Optical Transceiver,QSFP28,100GE,Multi-mode Module(850nm,0.075km-OM3,0.1km-OM4,LC)
|
||
|
02313HLU
|
QSFP-100G-ER4
|
100GBase-ER4 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,40km,LC)
|
||
|
02314HES
|
QSFP-100G-ER4
|
100GBase-ER4 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,40km,LC)
|
||
|
02314BDE
|
QSFP-100G-FR1
|
100GBase-FR1 Transceiver,QSFP28,100G,Single-mode Module(1310nm,2km,LC)
|
||
|
02314DBX
|
QSFP-100G-LX4-MM
|
High Speed Transceiver,QSFP28,1310nm,4*25.78G,-3dBm,4.5dBm,-10dBm,LC,MMF,0.1km
|
||
|
02312QTL
|
QSFP-100G-4WDM-40
|
100GBase-4WDM-40 Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,40km,LC)
|
||
|
02312UJN
|
QSFP-100G-CWDM4-Lite
|
100GBase-CWDM4-Lite Optical Transceiver,QSFP28,100G,Single-mode module (1310nm,0.5km,LC)
|
||
|
2315286
|
SFP-GE-LX-SM1490-BIDI
|
Optical Transceiver,eSFP,GE,BIDI Single-mode Module(TX1490/RX1310,10km,LC)
|
||
|
02314KKH
|
SFP-GE-LX-SM1490-BIDI
|
Optical Transceiver,eSFP,GE,BIDI Single-mode Module(TX1490/RX1310,10km,LC)
|
||
|
2315285
|
SFP-GE-LX-SM1310-BIDI
|
Optical Transceiver,eSFP,GE,BIDI Single-mode Module(TX1310/RX1490,10km,LC)
|
||
|
02314KKJ
|
SFP-GE-LX-SM1310-BIDI
|
Optical Transceiver,eSFP,GE,BIDI Single-mode Module(TX1310/RX1490,10km,LC)
|
||
|
02310KVU
|
LE2MGSC40ED0
|
Optical Transceiver,eSFP,GE,BIDI Single-mode Module(TX1490/RX1310,40km,LC)
|
||
|
02310KVV
|
LE2MGSC40DE0
|
Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1310/RX1490, 40km, LC)
|
||
|
02310QBJ
|
SFP-10G-BXU1
|
10GBase,BIDI Optical Transceiver,SFP+,10G,Single-mode Module(TX1270nm/RX1330nm,10km,LC)
|
||
|
02310QDT
|
SFP-10G-BXD1
|
10GBase,BIDI Optical Transceiver,SFP+,10G,Single-mode Module(TX1330nm/RX1270nm,10km,LC)
|
||
|
02311BJB
|
SFP-10G-ER-SM1330-BIDI
|
Optical Transceiver,SFP+,10G,BIDI Single-mode Module(TX 1330nm/RX 1270nm,40km,LC)
|
||
|
02311BJC
|
SFP-10G-ER-SM1270-BIDI
|
Optical Transceiver,SFP+,10G,BIDI Single-mode Module(TX 1270nm/RX 1330nm,40km,LC)
|
||
|
High Speed Cable
|
|
|
||
|
02310QWH
|
SFP-10G-AOC10M
|
AOC Optical Transceiver,SFP+,850nm,1G~10G,10m
|
||
|
02311KNQ
|
QSFP-100G-AOC-10M
|
Active Optical Cable ,QSFP28,100G,(850nm,10m,AOC)
|
||
|
02311RAH
|
QSFP-100G-AOC-30M
|
Active Optical Cable ,QSFP28,100G,(850nm,30m,AOC)
|
||
|
02310MUN
|
SFP-10G-CU1M
|
SFP+,10G,High Speed Direct-attach Cables,1m,SFP+20M,CC2P0.254B(S),SFP+20M,Used indoor
|
||
|
02310MUP
|
SFP-10G-CU3M
|
SFP+,10G,High Speed Direct-attach Cables,3m,SFP+20M,CC2P0.254B(S),SFP+20M,Used indoor
|
||
|
02310QPR
|
SFP-10G-CU5M
|
SFP+,10G,High Speed Cable,5m,SFP+20M,CC2P0.254B(S),SFP+20M,LSFRZH For Indoor
|
||
|
02310MUG
|
QSFP-40G-CU1M
|
QSFP+,40G,High Speed Direct-attach Cables,1m,QSFP+38M,CC8P0.254B(S),QSFP+38M,Used indoor
|
||
|
02310MUH
|
QSFP-40G-CU3M
|
QSFP+,40G,High Speed Direct-attach Cables,3m,QSFP+38M,CC8P0.32B(S),QSFP+38M,Used indoor
|
||
|
02310MUJ
|
QSFP-40G-CU5M
|
QSFP+,40G,High Speed Direct-attach Cables,5m,QSFP+38M,CC8P0.40B(S),QSFP+38M,Used indoor
|
||
|
02310MUM
|
QSFP-4SFP10G-CU5M
|
QSFP+,4SFP+10G,High Speed Direct-attach Cables,5m,QSFP+38M,CC8P0.4B(S),4*SFP+20M,Used indoor
|
||
|
02310MUL
|
QSFP-4SFP10G-CU3M
|
QSFP+,4SFP+10G,High Speed Direct-attach Cables,3m,QSFP+38M,CC8P0.32B(S),4*SFP+20M,Used indoor
|
||
|
02311KNW
|
QSFP28-100G-CU1M
|
QSFP28,100G,High Speed Direct-attach Cables,1m,(QSFP28),CC8P0.254B(S),QSFP28,Used indoor
|
||
|
02311KNX
|
QSFP28-100G-CU3M
|
QSFP28,100G,High Speed Direct-attach Cables,3m,(QSFP28),CC8P0.254B(S),QSFP28,Used indoor
|
||
|
02311KNY
|
QSFP28-100G-CU5M
|
QSFP28,100G,High Speed Direct-attach Cables,5m,(QSFP28),CC8P0.4B(S),QSFP28,Used indoor
|
||
|
Software
|
|
|
||
|
88038HBE
|
L-MLIC-S167
|
S167 Series Basic SW,Per Device
|
||
|
88038GGY
|
N1-S167-M-Lic
|
S167 Series Basic SW,Per Device
|
||
|
88062YEV
|
N1-S167-M-SnS-3Y
|
S167 Series Basic SW,SnS,Per Device,3 Year
|
||
|
88038GGV
|
N1-S167-F-Lic
|
N1-CloudCampus,Foundation,S167 Series,Per Device
|
||
|
88062YFA
|
N1-S167-F-SnS-3Y
|
N1-CloudCampus,Foundation,S167 Series,SnS,Per Device,3 Year( Annual fee validity period:3 years from" 90 days after PO signed" )
|
||
|
88038GVY
|
N1-S167-A-Lic
|
N1-CloudCampus,Advanced,S167 Series,Per Device
|
||
|
88062YFE
|
N1-S167-A-SnS-3Y
|
N1-CloudCampus,Advanced,S167 Series,SnS,Per Device,3 Year
|
||
|
88038HAK
|
N1-S167-MToF-Lic
|
N1-Upgrade-Basic Software to Foundation,S167 Series,Per Device
|
||
|
88062YFU
|
N1-S167-MToF-SnS-3Y
|
N1-Upgrade-Basic Software to Foundation,S167 Series,SnS,Per Device,3 Year
|
||
|
88038GWA
|
N1-S167-FToA-Lic
|
N1-Upgrade-Foundation to Advanced,S167 Series,Per Device
|
||
|
88062YFJ
|
N1-S167-FToA-SnS-3Y
|
N1-Upgrade-Foundation to Advanced,S167 Series,SnS,Per Device,3 Year
|
||
|
88036KSK
|
N1-AM-30-Lic
|
N1-CloudCampus, Add-On Package, Access Management, Per 30 Endpoints
|
||
|
88062GMD
|
N1-AM-30-SnS-3Y
|
N1-CloudCampus, Add-On Package, Access Management, Software Subscription and Support, Per 30 Endpoints,3 Years
|
||
|
88036KSL
|
N1-EPNP-30-Lic
|
N1-CloudCampus, Add-On Package, Endpoints Plug and Play, Per 30 Endpoints
|
||
|
88062GMH
|
N1-EPNP-30-SnS-3Y
|
N1-CloudCampus, Add-On Package, Endpoints Plug and Play, Software Subscription and Support, Per 30 Endpoints,3 Years
|
||
|
88036KSM
|
N1-APP-X7MSwitch
|
N1-CloudCampus, Add-On Package, Intelligent Application Analysis, X7 Series Modular Switch, Per Device
|
||
|
88062GMT
|
N1-APP-X7MSwitch-SnS-3Y
|
N1-CloudCampus, Add-On Package, Intelligent Application Analysis, X7 Series Modular Switch, Software Subscription and Support, Per
Device,3 Year |
||
|
88038HAP
|
N1-S167-SRv6-Lic
|
N1-CloudCampus,Add-On Package,SRv6,S167 Series,Per Device
|
||
|
88062YGL
|
N1-S167-SRv6-SnS-3Y
|
N1-CloudCampus,Add-On Package,SRv6,S167 Series,SnS,Per Device,3 Year
|
||
Related Products
S6700-48-EI
CE6870-48T6CQ-EI
5950-36TM-H-AC
Hot Products
Contactez-nous
Yantai Boxin International Trade Co., Ltd.
Cliquez sur le num?ro pour discuter sur WhatsApp ou envoyer un email. L'ID WeChat est le m?me que le num?ro de t?l?phone.
Spécifications techniques
Fréquences et bandes
Supports 2G/3G/4G/5G frequency bands. Detailed band specifications depend on the specific model and configuration. Contact our sales team for the exact band coverage of your target market.
Interfaces et connecteurs
Standard telecom interfaces including optical ports, RF connectors, Ethernet ports and power interfaces. Connector types and quantities vary by product model. Full interface specifications available in the product datasheet.
Alimentation et consommation
Operating voltage range, power consumption and power supply requirements differ by equipment type. Typical operating temperature range: -40°C to +55°C. Detailed power specifications provided on request.
Certifications et conformité
Products comply with CE, RoHS, FCC and ISO 9001 standards where applicable. Certification documents and test reports are available for verified B2B customers upon request.
Compatibilité et déploiement
Compatible with major telecom infrastructure vendors. Suitable for indoor and outdoor deployment scenarios including base stations, transmission nodes and optical distribution networks. Custom configurations available for large-scale projects.
Demander un devis en gros
Besoin de ce produit en volume ? Contactez notre équipe pour des prix B2B, la personnalisation et la livraison. Réponse sous 24 heures.
