For Wireless Base Station RRU R8852E S1800 Network Coverage Signal Strength Twelve Months Warranty

Name: For Wireless Base Station RRU R8852E S1800 Network Coverage Signal Strength Twelve Months Warranty
SKU: 1601721199925_R8852E S1800
Price: 499.85 USD
Availability: InStock

$499.85 USD

Couleur

R8852E S1800

Demander un devis

Product descriptions from the supplier

Hardware Structure

Figure1 shows the hardware structure of the ZXSDR R8852E.

Figure1 Hardware Structure

1,Handle

2,Indicators

3,Maintenance cavity

4,Bottom interface

Basic Functions

The ZXSDR R8852E supports the following functions:

Supports 900 MHz, 1800 MHz and 2100 MHz frequency bands.

Supports LTE configuration of 1.4 MHz/3 MHz/5 MHz/10 MHz in 900 MHz, 1.4 MHz/3 MHz/5 MHz/10 MHz/15 MHz/20 MHz scalable bandwidth in 1800 MHz, and 5 MHz/10 MHz/15 MHz/20 MHz in 2100 MHz.

Supports 2T4R, which can optimize spectrum efficiency greatly and improve network uplink performance.

Supports 256QAM in LTE downlinks and 64QAM in uplinks.

Supports the transmit power reporting function for every carrier.

Supports the overload protection function for the power amplifier.

Supports the transmit channel switching on/off function.

Supports non-interruptible services in adjacent modules in case of one R8852E software failure.

Environmental Requirements

Power Supply

Item	Description
Power supply	DC: -48 V (-37 V to -57 V DC)

Operating Environment

Item	Description
Temperature	– 40 °C to +55 °C
Relative humidity	5% to 100%
Atmospheric pressure	70 kPa to 106 kPa
Waterproof and dust-proof protection rating	IP65
Grounding	≤5 Ω; earth resistance can be less than 10 Ω in thunder-less area where thunderstorm days is less than 20 per year.
Storage environment	ETSI EN 300019-1-1 Class 1.2 “Weather protected, not temperature-controlled storage locations” When the storage environment conditions specified in the above standards are met, the product can operate properly within a storage period of one year.

Contactez-nous

Yantai Boxin International Trade Co., Ltd.

Huijiang · Ventes

WhatsApp / WeChat / Phone

+86 185 5406 5950

[email protected]

Anna · Ventes

WhatsApp / WeChat / Phone

+86 186 6382 8268

[email protected]

Cliquez sur le numéro pour discuter sur WhatsApp ou envoyez un e-mail. L'identifiant WeChat est le même que le numéro.

For Wireless Base Station RRU R8852E S1800 Network Coverage Signal Strength Twelve Months

Spécifications techniques

Fréquences et bandes

Supports 2G/3G/4G/5G frequency bands. Detailed band specifications depend on the specific model and configuration. Contact our sales team for the exact band coverage of your target market.

Interfaces et connecteurs

Standard telecom interfaces including optical ports, RF connectors, Ethernet ports and power interfaces. Connector types and quantities vary by product model. Full interface specifications available in the product datasheet.

Alimentation et consommation

Operating voltage range, power consumption and power supply requirements differ by equipment type. Typical operating temperature range: -40°C to +55°C. Detailed power specifications provided on request.

Certifications et conformité

Products comply with CE, RoHS, FCC and ISO 9001 standards where applicable. Certification documents and test reports are available for verified B2B customers upon request.

Compatibilité et déploiement

Compatible with major telecom infrastructure vendors. Suitable for indoor and outdoor deployment scenarios including base stations, transmission nodes and optical distribution networks. Custom configurations available for large-scale projects.
