HUAWEIS MU739 3G HSPA+ LGA Module
Yantai Boxin International Trading Co., Ltd. is a professional comprehensive trading service provider for communication equipment.With warehouses established in Yantai and Hong Kong, we have built a complete and localized network for delivering communication products and services.In 2018, Yantai Boxin International Trading Co., Ltd. set up its international sales department in Yantai, China.Based in China, we operate in emerging markets across Southeast Asia, India, the Middle East, Africa, Europe, and the United States.
Yantai Boxin International Trading Co., Ltd. supplies products to various telecom operators, meeting their needs for supplementing and expanding 2G/3G/4G/5G network stations.Our current equipment portfolio covers brands such as Nokia, Ericsson, Alcatel, Huawei, ZTE, ZTT, and FiberHome.
We expand our international market share by offering high-quality products, excellent service, competitive pricing, and timely delivery.Feel free to contact us for more information.
Huawei MU739 is one of the world's slimmest and most compact 3G/HSPA+ modules.It has a 114-pin LGA connector and features an USB interface, JTAG and is hardware prepared for IPC and I2S Digital Voice.Huawei MU739 module supports the HSPA+ network with a download speed up to 21 Mbps, satisfying consumer demand for high speed surfing.The HUAWEI MU739 supports UMTS 5-band global roaming and is slimmer and smaller compared with HSPA+ modules on the market, while consuming less power and emitting less heat.
HUAWEI MU739 Especificações técnicas:
* Form Factor: LGA module
* World's smallest PA+ module
* Frequency Bands:
- WCDMA/HSDPA/HSUPA/HSPA+: 850/900/1700(AWS)/1900/2100MHz
- GSM/GPRS/EDGE: 850/900/1800/1900MHz
* Data rates Speed:
- HSPA+: UL 5.76Mbps/DL 21.6Mbps
- WCDMA PS: UL 384kbps/DL 384kbps
- WCDMA CS: UL 64kbps/DL 64kbps
- EDGE: Download 236.8kbps/Upload: 236.8kbps
- GPRS: UL 85.6kbps/DL 85.6kbps
- GSM CS: UL 14.4kbps/DL 14.4kbps
* Interface:
- Antenna interfaces x 2
- 114-pin LGA connector
- Power supply
- USB 2.0 high speed
- UICC interface
* SMS
- New message alert, text message receiving, and text message sending
- Management of text messages: read messages, delete messages, storage status and message list
- Supporting MO and MT.
- to -point and cell broadcast
- Supporting formats of TEXT and PDU
* Dimensions: 20 x 30 x 2.0mm
* Supports Windows XP/7/8, Android 4.0
Contate-nos
Yantai Boxin International Trade Co., Ltd.
Clique no n?mero para conversar no WhatsApp ou enviar um email. O ID do WeChat ? o mesmo que o n?mero de telefone.
Especificações técnicas
Frequência e bandas
Supports 2G/3G/4G/5G frequency bands. Detailed band specifications depend on the specific model and configuration. Contact our sales team for the exact band coverage of your target market.
Interfaces e conectores
Standard telecom interfaces including optical ports, RF connectors, Ethernet ports and power interfaces. Connector types and quantities vary by product model. Full interface specifications available in the product datasheet.
Energia e consumo
Operating voltage range, power consumption and power supply requirements differ by equipment type. Typical operating temperature range: -40°C to +55°C. Detailed power specifications provided on request.
Certificações e conformidade
Products comply with CE, RoHS, FCC and ISO 9001 standards where applicable. Certification documents and test reports are available for verified B2B customers upon request.
Compatibilidade e implantação
Compatible with major telecom infrastructure vendors. Suitable for indoor and outdoor deployment scenarios including base stations, transmission nodes and optical distribution networks. Custom configurations available for large-scale projects.
Solicitar orçamento em massa
Precisa deste produto em volume? Fale com vendas para preços B2B, personalização e envio. Respondemos em 24 horas.
